| 型号 |
外部尺寸（mm） |
工作温度（℃） |
频率范围 |
PDF下载 |
| 19.2MHz贴片晶振 2520晶振 NX2520SA-19.200000MHZ-NBG1 13PF 20PPM NDK晶振 |
2.5×2.0×0.50mm |
-- |
19.2MHz |
PDF下载 |
| 20MHz贴片晶振 2520晶振 NX2520SA-20.000M-STD-CSW-4 8PF 15PPM |
2.5×2.0×0.50mm |
-- |
20MHz |
PDF下载 |
| NX2520SA-25.000M-STD-CSW-4 25MHz贴片晶振 2520封装 8PF 15PPM NDK晶振 |
2.5×2.0×0.50mm |
-- |
25MHz |
PDF下载 |
| 16MHz贴片无源晶振 NX2520SA-16.000M-STD-CSW-4 NDK晶振 8PF 15PPM |
2.5×2.0×0.50mm |
-- |
16MHz |
PDF下载 |
| 24MHz贴片晶振 2520晶振 NX2520SA-24.000M-STD-CSW-4 8PF 15PPM NDK晶振 |
2.5×2.0×0.50mm |
-- |
24MHz |
PDF下载 |
| 27MHz贴片晶振 2520晶振 NX2520SA-27MHZ-STD-CSW-5 8PF 15PPM |
2.5×2.0×0.50mm |
-- |
27MHz |
PDF下载 |
| 26MHz蓝牙晶振 3225晶振 NX3225SA-26.000MHZ-EXS00A-CS03865 16PF 15PPM |
3.2×2.5×0.55mm |
-- |
26MHz |
PDF下载 |
| 12MHz贴片无源晶振 NX3225SA-12.000M-STD-CSR-6 NDK晶振 8PF 15PPM |
3.2×2.5×0.55mm |
-- |
12MHz |
PDF下载 |
| 16MHz无源晶振 3225封装 NX3225SA-16.000M-STD-CSR-6 NDK晶振 8PF |
3.2×2.5×0.55mm |
-- |
16MHz |
PDF下载 |
| 16MHz蓝牙晶振 3225贴片晶振 NX3225SA 16.000MHZ STD-CRS-2 8PF |
3.2×2.5×0.55mm |
-- |
16MHz |
PDF下载 |
| 18.432MHz贴片晶振 NX3225SA-18.432M-STD-CSR-3 8PF 15PPM晶振 |
3.2×2.5×0.55mm |
-- |
18.432MHz |
PDF下载 |
| 40MHz无源晶振 3225晶振 NX3225SA-40.000M-STD-CSR-6 NDK晶振 8PF |
3.2×2.5×0.55mm |
-- |
40MHz |
PDF下载 |
| 24MHz贴片晶振 3225晶振 NX3225SA-24.000MHZ-STD-CRS-2 NDK晶振 8PF |
3.2×2.5×0.55mm |
-- |
24MHz |
PDF下载 |
| 19.2MHz贴片晶振 NX3225SA-19.200M-STD-CSR-6 8PF NDK晶振 |
3.2×2.5×0.55mm |
-- |
19.2MHz |
PDF下载 |
| 16.8MHz贴片晶振 3225晶振 NX3225SA-16.800M-STD-CSR-3 NDK晶振 8PF |
3.2×2.5×0.55mm |
-- |
16.8MHz |
PDF下载 |
| 12MHz贴片无源晶振 NX3225SA-12.00M-STD-CRS-2 8PF 3225贴片NDK晶振 |
3.2×2.5×0.55mm |
-- |
12MHz |
PDF下载 |
| 30MHz贴片 NX3225SA-30.000M-STD-CSR-6 8PF晶振 |
3.2×2.5×0.55mm |
-- |
30MHz |
PDF下载 |
| 27MHz贴片晶振 3225晶振 NX3225SA-27.000M-STD-CSR-6 NDK晶振 8PF |
3.2×2.5×0.55mm |
-- |
27MHz |
PDF下载 |
| 30MHz无源晶振 3225晶振 NX3225SA-30.00M-STD-CSR-3 8PF 15PPM |
3.2×2.5×0.55mm |
-- |
30MHz |
PDF下载 |
| 27MHz晶振 3225晶振 NX3225SA-27.120M-STD-CSR-1 8PF晶振 |
3.2×2.5×0.55mm |
-- |
27MHz |
PDF下载 |
