Q33615012077400晶振,25MHz晶振,SG-615P,4.5V-5.5V,

产品分类：晶振规格书

特征：频率范围:1.025 MHz ~ 26 MHz,电源电压:5.0V Typ.功能:使能(OE)

订购热线： 0755-33533774

跟此产品相关的产品

产品详情

型号	料号	尺寸	电压	频率
SG-615P	Q33615012078800	14.0 x 9.8x4.7mm	4.5V-5.5V	12MHz
SG-615P	Q33615012077400	14.0 x 9.8x4.7mm	4.5V-5.5V	25MHz
SG-615P	Q33615012077200	14.0 x 9.8x4.7mm	4.5V-5.5V	20MHz
SG-615P	Q33615012076300	14.0 x 9.8x4.7mm	4.5V-5.5V	24MHz
SG-615P	Q33615012075800	14.0 x 9.8x4.7mm	4.5V-5.5V	16MHz
SG-615P	Q33615012069700	14.0 x 9.8x4.7mm	4.5V-5.5V	16MHz
SG-615P	Q33615012067400	14.0 x 9.8x4.7mm	4.5V-5.5V	16.777MHz
SG-615P	Q33615012067300	14.0 x 9.8x4.7mm	4.5V-5.5V	24MHz
SG-615P	Q33615012042200	14.0 x 9.8x4.7mm	4.5V-5.5V	13.56MHz
SG-615P	Q33615012031400	14.0 x 9.8x4.7mm	4.5V-5.5V	1.9968MHz
SG-615P	Q33615012026800	14.0 x 9.8x4.7mm	4.5V-5.5V	1.8432MHz
SG-615P	Q33615012025000	14.0 x 9.8x4.7mm	4.5V-5.5V	11MHz
SG-615P	Q33615012024300	14.0 x 9.8x4.7mm	4.5V-5.5V	16.552MHz
SG-615P	Q33615012017000	14.0 x 9.8x4.7mm	4.5V-5.5V	1.125MHz
SG-615P	Q33615012016900	14.0 x 9.8x4.7mm	4.5V-5.5V	21.818MHz
SG-615P	Q33615012014900	14.0 x 9.8x4.7mm	4.5V-5.5V	20.2752MHz
SG-615P	Q33615012011500	14.0 x 9.8x4.7mm	4.5V-5.5V	8.064MHz
SG-615P	Q33615012009900	14.0 x 9.8x4.7mm	4.5V-5.5V	2.048MHz
SG-615P	Q33615012009800	14.0 x 9.8x4.7mm	4.5V-5.5V	20.48MHz
SG-615P	Q33615012009500	14.0 x 9.8x4.7mm	4.5V-5.5V	12.5MHz
SG-615P	Q33615012009300	14.0 x 9.8x4.7mm	4.5V-5.5V	25.175MHz
SG-615P	Q33615012009100	14.0 x 9.8x4.7mm	4.5V-5.5V	4.096MHz
SG-615P	Q33615012008900	14.0 x 9.8x4.7mm	4.5V-5.5V	16.6667MHz
SG-615P	Q33615012008700	14.0 x 9.8x4.7mm	4.5V-5.5V	8.192MHz
SG-615P	Q33615012008500	14.0 x 9.8x4.7mm	4.5V-5.5V	22.1184MHz
SG-615P	Q33615012008300	14.0 x 9.8x4.7mm	4.5V-5.5V	12.8MHz
SG-615P	Q33615012007700	14.0 x 9.8x4.7mm	4.5V-5.5V	25MHz
SG-615P	Q33615012007600	14.0 x 9.8x4.7mm	4.5V-5.5V	18MHz
SG-615P	Q33615012007000	14.0 x 9.8x4.7mm	4.5V-5.5V	14.7456MHz
SG-615P	Q33615012006900	14.0 x 9.8x4.7mm	4.5V-5.5V	14.7456MHz
SG-615P	Q33615012006700	14.0 x 9.8x4.7mm	4.5V-5.5V	11.0592MHz
SG-615P	Q33615012006200	14.0 x 9.8x4.7mm	4.5V-5.5V	24MHz
SG-615P	Q33615012006100	14.0 x 9.8x4.7mm	4.5V-5.5V	19.2MHz
SG-615P	Q33615012006000	14.0 x 9.8x4.7mm	4.5V-5.5V	9.6MHz
SG-615P	Q33615012005700	14.0 x 9.8x4.7mm	4.5V-5.5V	1.8432MHz
SG-615P	Q33615012005500	14.0 x 9.8x4.7mm	4.5V-5.5V	3.6864MHz
SG-615P	Q33615012005200	14.0 x 9.8x4.7mm	4.5V-5.5V	7.3728MHz
SG-615P	Q33615012005000	14.0 x 9.8x4.7mm	4.5V-5.5V	1.544MHz
SG-615P	Q33615012004900	14.0 x 9.8x4.7mm	4.5V-5.5V	1.544MHz
SG-615P	Q33615012004700	14.0 x 9.8x4.7mm	4.5V-5.5V	3.579545MHz
SG-615P	Q33615012004500	14.0 x 9.8x4.7mm	4.5V-5.5V	14.31818MHz
SG-615P	Q33615012004400	14.0 x 9.8x4.7mm	4.5V-5.5V	14.31818MHz
SG-615P	Q33615012004000	14.0 x 9.8x4.7mm	4.5V-5.5V	6MHz
SG-615P	Q33615012003700	14.0 x 9.8x4.7mm	4.5V-5.5V	12MHz
SG-615P	Q33615012003600	14.0 x 9.8x4.7mm	4.5V-5.5V	1.536MHz
SG-615P	Q33615012003400	14.0 x 9.8x4.7mm	4.5V-5.5V	6.144MHz
SG-615P	Q33615012003300	14.0 x 9.8x4.7mm	4.5V-5.5V	12.288MHz
SG-615P	Q33615012003200	14.0 x 9.8x4.7mm	4.5V-5.5V	2MHz
SG-615P	Q33615012003000	14.0 x 9.8x4.7mm	4.5V-5.5V	4MHz
SG-615P	Q33615012002800	14.0 x 9.8x4.7mm	4.5V-5.5V	8MHz
SG-615P	Q33615012002100	14.0 x 9.8x4.7mm	4.5V-5.5V	18.432MHz
SG-615P	Q33615012001800	14.0 x 9.8x4.7mm	4.5V-5.5V	2.4576MHz
SG-615P	Q33615012001700	14.0 x 9.8x4.7mm	4.5V-5.5V	4.9152MHz
SG-615P	Q33615012001400	14.0 x 9.8x4.7mm	4.5V-5.5V	9.8304MHz
SG-615P	Q33615012001200	14.0 x 9.8x4.7mm	4.5V-5.5V	19.6608MHz
SG-615P	Q33615012001100	14.0 x 9.8x4.7mm	4.5V-5.5V	19.6608MHz
SG-615P	Q33615012001000	14.0 x 9.8x4.7mm	4.5V-5.5V	2.5MHz
SG-615P	Q33615012000800	14.0 x 9.8x4.7mm	4.5V-5.5V	5MHz
SG-615P	Q33615012000500	14.0 x 9.8x4.7mm	4.5V-5.5V	10MHz
SG-615P	Q33615012000100	14.0 x 9.8x4.7mm	4.5V-5.5V	20MHz
SG-615P	Q33615011082700	14.0 x 9.8x4.7mm	4.5V-5.5V	4.61MHz
SG-615P	Q33615011082600	14.0 x 9.8x4.7mm	4.5V-5.5V	20.72MHz
SG-615P	Q33615011082500	14.0 x 9.8x4.7mm	4.5V-5.5V	16.55172MHz
SG-615P	Q33615011082400	14.0 x 9.8x4.7mm	4.5V-5.5V	3.39MHz
SG-615P	Q33615011082300	14.0 x 9.8x4.7mm	4.5V-5.5V	10.025MHz
SG-615P	Q33615011082200	14.0 x 9.8x4.7mm	4.5V-5.5V	16.38MHz
SG-615P	Q33615011082000	14.0 x 9.8x4.7mm	4.5V-5.5V	7MHz
SG-615P	Q33615011081400	14.0 x 9.8x4.7mm	4.5V-5.5V	12.88MHz
SG-615P	Q33615011081200	14.0 x 9.8x4.7mm	4.5V-5.5V	4.8MHz
SG-615P	Q33615011080800	14.0 x 9.8x4.7mm	4.5V-5.5V	2.22MHZ
SG-615P	Q33615011080700	14.0 x 9.8x4.7mm	4.5V-5.5V	14.285MHz
SG-615P	Q33615011079300	14.0 x 9.8x4.7mm	4.5V-5.5V	1.228MHz
SG-615P	Q33615011079200	14.0 x 9.8x4.7mm	4.5V-5.5V	20.945MHz
SG-615P	Q33615011078500	14.0 x 9.8x4.7mm	4.5V-5.5V	14.5MHz
SG-615P	Q33615011078300	14.0 x 9.8x4.7mm	4.5V-5.5V	21.4MHz
SG-615P	Q33615011078200	14.0 x 9.8x4.7mm	4.5V-5.5V	3.5795MHz
SG-615P	Q33615011078000	14.0 x 9.8x4.7mm	4.5V-5.5V	11.0592MHz
SG-615P	Q33615011077900	14.0 x 9.8x4.7mm	4.5V-5.5V	10MHz
SG-615P	Q33615011077000	14.0 x 9.8x4.7mm	4.5V-5.5V	16.384MHz
SG-615P	Q33615011076900	14.0 x 9.8x4.7mm	4.5V-5.5V	12.288MHz
SG-615P	Q33615011076200	14.0 x 9.8x4.7mm	4.5V-5.5V	3.1457MHz
SG-615P	Q33615011074400	14.0 x 9.8x4.7mm	4.5V-5.5V	3.2MHz
SG-615P	Q33615011074300	14.0 x 9.8x4.7mm	4.5V-5.5V	13.56MHz
SG-615P	Q33615011073900	14.0 x 9.8x4.7mm	4.5V-5.5V	1.415MHz
SG-615P	Q33615011071200	14.0 x 9.8x4.7mm	4.5V-5.5V	1.47456MHz
SG-615P	Q33615011051200	14.0 x 9.8x4.7mm	4.5V-5.5V	24.2937MHz
SG-615P	Q33615011049900	14.0 x 9.8x4.7mm	4.5V-5.5V	3.276MHz
SG-615P	Q33615011049000	14.0 x 9.8x4.7mm	4.5V-5.5V	7.15909MHz
SG-615P	Q33615011048600	14.0 x 9.8x4.7mm	4.5V-5.5V	5.1784MHz
SG-615P	Q33615011048200	14.0 x 9.8x4.7mm	4.5V-5.5V	17.7345MHz
SG-615P	Q33615011047900	14.0 x 9.8x4.7mm	4.5V-5.5V	1.96608MHz
SG-615P	Q33615011046800	14.0 x 9.8x4.7mm	4.5V-5.5V	6.66MHz
SG-615P	Q33615011046200	14.0 x 9.8x4.7mm	4.5V-5.5V	6.94MHz
SG-615P	Q33615011045700	14.0 x 9.8x4.7mm	4.5V-5.5V	17.734475MHz
SG-615P	Q33615011043100	14.0 x 9.8x4.7mm	4.5V-5.5V	11.034482MHz
SG-615P	Q33615011036300	14.0 x 9.8x4.7mm	4.5V-5.5V	14.368MHz
SG-615P	Q33615011035200	14.0 x 9.8x4.7mm	4.5V-5.5V	24.992MHz
SG-615P	Q33615011035000	14.0 x 9.8x4.7mm	4.5V-5.5V	24.192MHz
SG-615P	Q33615011034900	14.0 x 9.8x4.7mm	4.5V-5.5V	13.0909MHz
SG-615P	Q33615011031500	14.0 x 9.8x4.7mm	4.5V-5.5V	6.4MHz
SG-615P	Q33615011029500	14.0 x 9.8x4.7mm	4.5V-5.5V	9.8304MHz
SG-615P	Q33615011028100	14.0 x 9.8x4.7mm	4.5V-5.5V	2MHz
SG-615P	Q33615011027300	14.0 x 9.8x4.7mm	4.5V-5.5V	12.21MHz
SG-615P	Q33615011026600	14.0 x 9.8x4.7mm	4.5V-5.5V	16.6666MHz
SG-615P	Q33615011026200	14.0 x 9.8x4.7mm	4.5V-5.5V	24.0024MHz
SG-615P	Q33615011024400	14.0 x 9.8x4.7mm	4.5V-5.5V	8MHz
SG-615P	Q33615011024200	14.0 x 9.8x4.7mm	4.5V-5.5V	8.192MHz
SG-615P	Q33615011022900	14.0 x 9.8x4.7mm	4.5V-5.5V	14MHz
SG-615P	Q33615011022200	14.0 x 9.8x4.7mm	4.5V-5.5V	11.059MHz
SG-615P	Q33615011022100	14.0 x 9.8x4.7mm	4.5V-5.5V	12.14685MHz
SG-615P	Q33615011022000	14.0 x 9.8x4.7mm	4.5V-5.5V	22.4MHz
SG-615P	Q33615011021900	14.0 x 9.8x4.7mm	4.5V-5.5V	11.2896MHz
SG-615P	Q33615011021600	14.0 x 9.8x4.7mm	4.5V-5.5V	14.318MHz
SG-615P	Q33615011021400	14.0 x 9.8x4.7mm	4.5V-5.5V	9.216MHz
SG-615P	Q33615011020900	14.0 x 9.8x4.7mm	4.5V-5.5V	16.5MHz
SG-615P	Q33615011020700	14.0 x 9.8x4.7mm	4.5V-5.5V	12.352MHz
SG-615P	Q33615011020500	14.0 x 9.8x4.7mm	4.5V-5.5V	16.64MHz
SG-615P	Q33615011020100	14.0 x 9.8x4.7mm	4.5V-5.5V	3.5712MHz
SG-615P	Q33615011019000	14.0 x 9.8x4.7mm	4.5V-5.5V	12.352MHz
SG-615P	Q33615011018400	14.0 x 9.8x4.7mm	4.5V-5.5V	1.536MHz
SG-615P	Q33615011017900	14.0 x 9.8x4.7mm	4.5V-5.5V	19.968MHz
SG-615P	Q33615011017600	14.0 x 9.8x4.7mm	4.5V-5.5V	4MHz
SG-615P	Q33615011014400	14.0 x 9.8x4.7mm	4.5V-5.5V	16.5MHz
SG-615P	Q33615011014200	14.0 x 9.8x4.7mm	4.5V-5.5V	16.666MHz
SG-615P	Q33615011014100	14.0 x 9.8x4.7mm	4.5V-5.5V	11.2896MHz
SG-615P	Q33615011014000	14.0 x 9.8x4.7mm	4.5V-5.5V	4.194304MHz
SG-615P	Q33615011013700	14.0 x 9.8x4.7mm	4.5V-5.5V	22.5792MHz
SG-615P	Q33615011013300	14.0 x 9.8x4.7mm	4.5V-5.5V	9.83MHz
SG-615P	Q33615011013100	14.0 x 9.8x4.7mm	4.5V-5.5V	21MHz
SG-615P	Q33615011012900	14.0 x 9.8x4.7mm	4.5V-5.5V	24.704MHz
SG-615P	Q33615011012700	14.0 x 9.8x4.7mm	4.5V-5.5V	26MHz
SG-615P	Q33615011012500	14.0 x 9.8x4.7mm	4.5V-5.5V	19.5MHz
SG-615P	Q33615011012100	14.0 x 9.8x4.7mm	4.5V-5.5V	16.67MHz
SG-615P	Q33615011011900	14.0 x 9.8x4.7mm	4.5V-5.5V	19MHz
SG-615P	Q33615011011600	14.0 x 9.8x4.7mm	4.5V-5.5V	3.2768MHz
SG-615P	Q33615011011100	14.0 x 9.8x4.7mm	4.5V-5.5V	24.576MHz
SG-615P	Q33615011010800	14.0 x 9.8x4.7mm	4.5V-5.5V	15.36MHz
SG-615P	Q33615011010700	14.0 x 9.8x4.7mm	4.5V-5.5V	15.36MHz
SG-615P	Q33615011010600	14.0 x 9.8x4.7mm	4.5V-5.5V	7.68MHz
SG-615P	Q33615011010500	14.0 x 9.8x4.7mm	4.5V-5.5V	7.68MHz
SG-615P	Q33615011010200	14.0 x 9.8x4.7mm	4.5V-5.5V	10.752MHz
SG-615P	Q33615011010000	14.0 x 9.8x4.7mm	4.5V-5.5V	2.048MHZ
SG-615P	Q33615011009700	14.0 x 9.8x4.7mm	4.5V-5.5V	20.48MHZ
SG-615P	Q33615011009400	14.0 x 9.8x4.7mm	4.5V-5.5V	12.5MHz
SG-615P	Q33615011009000	14.0 x 9.8x4.7mm	4.5V-5.5V	4.096MHz
SG-615P	Q33615011008400	14.0 x 9.8x4.7mm	4.5V-5.5V	22.1184MHz
SG-615P	Q33615011007400	14.0 x 9.8x4.7mm	4.5V-5.5V	16.384MHz
SG-615P	Q33615011007200	14.0 x 9.8x4.7mm	4.5V-5.5V	16.257MHz
SG-615P	Q33615011006600	14.0 x 9.8x4.7mm	4.5V-5.5V	10.24MHz
SG-615P	Q33615011006500	14.0 x 9.8x4.7mm	4.5V-5.5V	5.0688MHz
SG-615P	Q33615011005900	14.0 x 9.8x4.7mm	4.5V-5.5V	16.128MHz
SG-615P	Q33615011005400	14.0 x 9.8x4.7mm	4.5V-5.5V	3.6864MHz
SG-615P	Q33615011005100	14.0 x 9.8x4.7mm	4.5V-5.5V	7.3728MHz
SG-615P	Q33615011004800	14.0 x 9.8x4.7mm	4.5V-5.5V	15MHz
SG-615P	Q33615011004200	14.0 x 9.8x4.7mm	4.5V-5.5V	3MHz
SG-615P	Q33615011004100	14.0 x 9.8x4.7mm	4.5V-5.5V	3MHz
SG-615P	Q33615011003500	14.0 x 9.8x4.7mm	4.5V-5.5V	3.072MHz
SG-615P	Q33615011002300	14.0 x 9.8x4.7mm	4.5V-5.5V	9.216MHz
SG-615P	Q33615011002000	14.0 x 9.8x4.7mm	4.5V-5.5V	18.432MHz
SG-615P	Q33615011001600	14.0 x 9.8x4.7mm	4.5V-5.5V	4.9152MHz
SG-615P	Q33615011000700	14.0 x 9.8x4.7mm	4.5V-5.5V	5MHz
