型号 | 频率 | 负载电容 | 精度 | 工作温度 |
NX8045GB-4.000M-STD-CJL-2 | 4MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-4.032M-STD-CJL-2 | 4.032MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-4.915M-STD-CJL-2 | 4.915MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-5.000M-STD-CSF-3 | 5MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-5.175M-STD-CSF-3 | 5.175MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-5.875M-STD-CSF-3 | 5.875MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-6.000M-STD-CSF-3 | 6MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-6.750M-STD-CSF-3 | 6.75MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-7.159M-STD-CSF-3 | 7.159MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-7.200M-STD-CSF-3 | 7.2MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-7.373M-STD-CSF-3 | 7.373MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-7.500M-STD-CSF-4 | 7.5MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-8.000M-STD-CSF-4 | 8MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-8.192M-STD-CSF-4 | 8.192MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-8.664M-STD-CSF-4 | 8.664MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-9.000M-STD-CSF-4 | 9MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-9.185M-STD-CSF-4 | 9.185MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-9.2160M-STD-CSF-4 | 9.216MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-9.509M-STD-CSF-4 | 9.509MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-9.830M-STD-CSF-4 | 9.83MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-9.844M-STD-CSF-4 | 9.844MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-9.862M-STD-CSF-4 | 9.862MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-9.864M-STD-CSF-4 | 9.864MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-10.000M-STD-CSF-4 | 10MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-10.178M-STD-CSF-4 | 10.178MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-10.250M-STD-CSF-4 | 10.25MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-11.000M-STD-CSF-4 | 11MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-11.059M-STD-CSF-4 | 11.059MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-11.250M-STD-CSF-4 | 11.25MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-11.290M-STD-CSF-4 | 11.29MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-11.895M-STD-CSF-4 | 11.895MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-11.968M-STD-CSF-4 | 11.968MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-12.000M-STD-CSF-4 | 12MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-12.288M-STD-CSF-4 | 12.288MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-12.332M-STD-CSF-4 | 12.332MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-12.500M-STD-CSF-4 | 12.5MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-12.580M-STD-CSF-4 | 12.58MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-13.000M-STD-CSF-4 | 13MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-13.084M-STD-CSF-4 | 13.084MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-13.125M-STD-CSF-4 | 13.125MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-13.226M-STD-CSF-4 | 13.226MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-13.333M-STD-CSF-4 | 13.333MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-13.400M-STD-CSF-4 | 13.4MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-13.500M-STD-CSF-4 | 13.5MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-13.560M-STD-CSF-4 | 13.56MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-13.565M-STD-CSF-4 | 13.565MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-13.567M-STD-CSF-4 | 13.567MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-13.569M-STD-CSF-4 | 13.569MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-13.57M-STD-CSF-4 | 13.57MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-13.574M-STD-CSF-4 | 13.574MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-13.576M-STD-CSF-4 | 13.576MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-13.578M-STD-CSF-4 | 13.578MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-13.581M-STD-CSF-4 | 13.581MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-13.750M-STD-CSF-4 | 13.75MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-13.824M-STD-CSF-4 | 13.824MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-13.913M-STD-CSF-4 | 13.913MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-14.000M-STD-CSF-4 | 14MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-14.130M-STD-CSF-4 | 14.13MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-14.264M-STD-CSF-4 | 14.264MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-14.285M-STD-CSF-4 | 14.285MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-14.318M-STD-CSF-4 | 14.318MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-14.464M-STD-CSF-4 | 14.464MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-14.746M-STD-CSF-4 | 14.746MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-15.000M-STD-CSF-4 | 15MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-15.360M-STD-CSF-4 | 15.36MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-15.974M-STD-CSF-4 | 15.974MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-16.000M-STD-CSF-4 | 16MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-16.128M-STD-CSF-4 | 16.128MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-16.200M-STD-CSF-4 | 16.2MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-16.384M-STD-CSF-4 | 16.384MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-16.500M-STD-CSF-4 | 16.5MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-16.666M-STD-CSF-4 | 16.666MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-16.777M-STD-CSF-4 | 16.777MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-16.900M-STD-CSF-4 | 16.9MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-16.915M-STD-CSF-4 | 16.915MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-16.920M-STD-CSF-4 | 16.92MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-16.934M-STD-CSF-4 | 16.934MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-17.258M-STD-CSF-4 | 17.258MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-17.664M-STD-CSF-4 | 17.664MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-17.734M-STD-CSF-4 | 17.734MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-18.000M-STD-CSF-4 | 18MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-18.080M-STD-CSF-4 | 18.08MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-18.106M-STD-CSF-4 | 18.106MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-18.432M-STD-CSF-4 | 18.432MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-18.438M-STD-CSF-4 | 18.438MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-18.938M-STD-CSF-4 | 18.938MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-19.000M-STD-CSF-4 | 19MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-19.07M-STD-CSF-4 | 19.07MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-19.176M-STD-CSF-4 | 19.176MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-19.200M-STD-CSF-4 | 19.2MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-19.247M-STD-CSF-4 | 19.247MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-19.661M-STD-CSF-4 | 19.661MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-19.800M-STD-CSF-4 | 19.8MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-20.000M-STD-CSF-4 | 20MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-20.250M-STD-CSF-4 | 20.25MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-20.480M-STD-CSF-4 | 20.48MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-20.500M-STD-CSF-4 | 20.5MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-21.047M-STD-CSF-4 | 21.047MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-21.120M-STD-CSF-4 | 21.12MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-21.477M-STD-CSF-4 | 21.477MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-21.544M-STD-CSF-4 | 21.544MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-22.118M-STD-CSF-4 | 22.118MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-22.579M-STD-CSF-4 | 22.579MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-22.909M-STD-CSF-4 | 22.909MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-24.000M-STD-CSF-4 | 24MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-24.545M-STD-CSF-4 | 24.545MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-24.576M-STD-CSF-4 | 24.576MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-25.000M-STD-CSF-4 | 25MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-25.140M-STD-CSF-4 | 25.14MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-25.670M-STD-CSF-4 | 25.67MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-25.805M-STD-CSF-4 | 25.805MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-26.000M-STD-CSF-4 | 26MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-26.973M-STD-CSF-4 | 26.973MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-26.980M-STD-CSF-4 | 26.98MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-27.000M-STD-CSF-4 | 27MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-27.120M-STD-CSF-4 | 27.12MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-27.500M-STD-CSF-4 | 27.5MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-27.700M-STD-CSF-4 | 27.7MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-27.824M-STD-CSF-4 | 27.824MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-28.000M-STD-CSF-4 | 28MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-28.224M-STD-CSF-4 | 28.224MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-28.322M-STD-CSF-4 | 28.322MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-28.375M-STD-CSF-4 | 28.375MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-28.496M-STD-CSF-4 | 28.496MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-28.500M-STD-CSF-4 | 28.5MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-28.636M-STD-CSF-4 | 28.636MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-29.000M-STD-CSF-4 | 29MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-29.491M-STD-CSF-4 | 29.491MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-29.499M-STD-CSF-4 | 29.499MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-30.000M-STD-CSF-4 | 30MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-30.275M-STD-CSF-4 | 30.275MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-30.720M-STD-CSF-4 | 30.72MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-31.400M-STD-CSF-4 | 31.4MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-32.000M-STD-CSF-4 | 32MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-32.720M-STD-CSF-4 | 32.72MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-32.768M-STD-CSF-4 | 32.768MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-33.000M-STD-CSF-4 | 33MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-33.231M-STD-CSF-4 | 33.231MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-33.333M-STD-CSF-4 | 33.333MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-33.869M-STD-CSF-4 | 33.869MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-35.328M-STD-CSF-4 | 35.328MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-35.469M-STD-CSF-4 | 35.469MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-35.638M-STD-CSF-4 | 35.638MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-36.000M-STD-CSF-4 | 36MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-36.200M-STD-CSF-4 | 36.2MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-36.818M-STD-CSF-4 | 36.818MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-36.864M-STD-CSF-4 | 36.864MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-37.500M-STD-CSF-4 | 37.5MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-38.000M-STD-CSF-4 | 38MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-38.035M-STD-CSF-4 | 38.035MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-38.352M-STD-CSF-4 | 38.352MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-38.400M-STD-CSF-4 | 38.4MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-40.000M-STD-CSF-4 | 40MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-41.600M-STD-CSF-4 | 41.6MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-42.955M-STD-CSF-4 | 42.955MHz | 8PF | 20PPM | -10~+70℃ |
NX8045GB-4.000M-STD-CJL-5 | 4MHz | 8PF | 30PPM | -40~+85℃ |
NX8045GB-4.032M-STD-CJL-5 | 4.032MHz | 8PF | 30PPM | -40~+85℃ |
NX8045GB-5.000M-STD-CSF-5 | 5MHz | 8PF | 30PPM | -40~+85℃ |
NX8045GB-6.000M-STD-CSF-5 | 6MHz | 8PF | 30PPM | -40~+85℃ |
NX8045GB-6.144M-STD-CSF-5 | 6.144MHz | 8PF | 30PPM | -40~+85℃ |
NX8045GB-7.200M-STD-CSF-5 | 7.2MHz | 8PF | 30PPM | -40~+85℃ |
NX8045GB-7.373M-STD-CSF-5 | 7.373MHz | 8PF | 30PPM | -40~+85℃ |
NX8045GB-7.500M-STD-CSF-6 | 7.5MHz | 8PF | 30PPM | -40~+85℃ |
NX8045GB-8.000M-STD-CSF-6 | 8MHz | 8PF | 30PPM | -40~+85℃ |
NX8045GB-9.000M-STD-CSF-6 | 9MHz | 8PF | 30PPM | -40~+85℃ |
NX8045GB-9.844M-STD-CSF-6 | 9.844MHz | 8PF | 30PPM | -40~+85℃ |
NX8045GB-10.000M-STD-CSF-6 | 10MHz | 8PF | 30PPM | -40~+85℃ |
NX8045GB-10.178M-STD-CSF-6 | 10.178MHz | 8PF | 30PPM | -40~+85℃ |
NX8045GB-12.000M-STD-CSF-6 | 12MHz | 8PF | 30PPM | -40~+85℃ |
NX8045GB-13.125M-STD-CSF-6 | 13.125MHz | 8PF | 30PPM | -40~+85℃ |
NX8045GB-13.226M-STD-CSF-6 | 13.226MHz | 8PF | 30PPM | -40~+85℃ |
NX8045GB-13.560M-STD-CSF-6 | 13.56MHz | 8PF | 30PPM | -40~+85℃ |
NX8045GB-13.581M-STD-CSF-6 | 13.581MHz | 8PF | 30PPM | -40~+85℃ |
NX8045GB-14.000M-STD-CSF-6 | 14MHz | 8PF | 30PPM | -40~+85℃ |
NX8045GB-15.000M-STD-CSF-6 | 15MHz | 8PF | 30PPM | -40~+85℃ |
NX8045GB-16.000M-STD-CSF-6 | 16MHz | 8PF | 30PPM | -40~+85℃ |
NX8045GB-18.000M-STD-CSF-6 | 18MHz | 8PF | 30PPM | -40~+85℃ |
NX8045GB-20.000M-STD-CSF-6 | 20MHz | 8PF | 30PPM | -40~+85℃ |
NX8045GB-24.000M-STD-CSF-6 | 24MHz | 8PF | 30PPM | -40~+85℃ |
NX8045GB-25.000M-STD-CSF-6 | 25MHz | 8PF | 30PPM | -40~+85℃ |
NX8045GB-26.000M-STD-CSF-6 | 26MHz | 8PF | 30PPM | -40~+85℃ |
NX8045GB-27.000M-STD-CSF-6 | 27MHz | 8PF | 30PPM | -40~+85℃ |
NX8045GB-30.000M-STD-CSF-6 | 30MHz | 8PF | 30PPM | -40~+85℃ |
NX8045GB-32.000M-STD-CSF-6 | 32MHz | 8PF | 30PPM | -40~+85℃ |
NX8045GB-33.000M-STD-CSF-6 | 33MHz | 8PF | 30PPM | -40~+85℃ |
NX8045GB-40.000M-STD-CSF-6 | 40MHz | 8PF | 30PPM | -40~+85℃ |
NX8045GB-7.50M-STD-CSJ-1 | 7.5MHz | 8PF | 50PPM | -40~+150℃ |
NX8045GB-8.000M-STD-CSJ-1 | 8MHz | 8PF | 50PPM | -40~+150℃ |
NX8045GB-9.000M-STD-CSJ-1 | 9MHz | 8PF | 50PPM | -40~+150℃ |
NX8045GB-9.844M-STD-CSJ-1 | 9.844MHz | 8PF | 50PPM | -40~+150℃ |
NX8045GB-10.000M-STD-CSJ-1 | 10MHz | 8PF | 50PPM | -40~+150℃ |
NX8045GB-10.178M-STD-CSJ-1 | 10.178MHz | 8PF | 50PPM | -40~+150℃ |
NX8045GB-12.000M-STD-CSJ-1 | 12MHz | 8PF | 50PPM | -40~+150℃ |
NX8045GB-13.125M-STD-CSJ-1 | 13.125MHz | 8PF | 50PPM | -40~+150℃ |
NX8045GB-13.226M-STD-CSJ-1 | 13.226MHz | 8PF | 50PPM | -40~+150℃ |
NX8045GB-13.560M-STD-CSJ-1 | 13.56MHz | 8PF | 50PPM | -40~+150℃ |
NX8045GB-13.581M-STD-CSJ-1 | 13.581MHz | 8PF | 50PPM | -40~+150℃ |
NX8045GB-14.000M-STD-CSJ-1 | 14MHz | 8PF | 50PPM | -40~+150℃ |
NX8045GB-15.000M-STD-CSJ-1 | 15MHz | 8PF | 50PPM | -40~+150℃ |
NX8045GB-16.000M-STD-CSJ-1 | 16MHz | 8PF | 50PPM | -40~+150℃ |
NX8045GB-18.000M-STD-CSJ-1 | 18MHz | 8PF | 50PPM | -40~+150℃ |
NX8045GB-20.000M-STD-CSJ-1 | 20MHz | 8PF | 50PPM | -40~+150℃ |
NX8045GB-24.000M-STD-CSJ-1 | 24MHz | 8PF | 50PPM | -40~+150℃ |
NX8045GB-25.000M-STD-CSJ-1 | 25MHz | 8PF | 50PPM | -40~+150℃ |
NX8045GB-26.000M-STD-CSJ-1 | 26MHz | 8PF | 50PPM | -40~+150℃ |
NX8045GB-30.000M-STD-CSJ-1 | 30MHz | 8PF | 50PPM | -40~+150℃ |
NX8045GB-32.000M-STD-CSJ-1 | 32MHz | 8PF | 50PPM | -40~+150℃ |
NX8045GB-33.000M-STD-CSJ-1 | 33MHz | 8PF | 50PPM | -40~+150℃ |
NX8045GB-40.000M-STD-CSJ-1 | 40MHz | 8PF | 50PPM | -40~+150℃ |
NX8045GE-4.000M-STD-CJL-6 | 4MHz | 8PF | 50PPM | -40~+150℃ |
NX8045GE-4.194M-STD-CJL-6 | 4.194MHz | 8PF | 50PPM | -40~+150℃ |
NX8045GE-5.000M-STD-CJL-6 | 5MHz | 8PF | 50PPM | -40~+150℃ |
NX8045GE-6.000M-STD-CJL-6 | 6MHz | 8PF | 50PPM | -40~+150℃ |
NX8045GE-8.000M-STD-CJL-6 | 8MHz | 8PF | 50PPM | -40~+150℃ |
betway888必威 简介
betway888必威 晶振产品广泛应用于交换机和路由器,光纤通信系统,卫星通信,雷达,导航和传感等领域,在交换机和路由器中,NDK进口晶振凭借其卓越的性能和广泛的应用领域,成为了电子领域中不可或缺的重要元件,为现代通信和物联网技术的发展提供了有力支持,随着未来通信技术的不断进步和应用领域的拓展,NDK晶振的需求和应用前景将更加广阔,在其它领域如电子设备的时钟源,微处理器的频率参考等,也有着广泛的应用,总的来说,NDK晶振以其卓越的性能和广泛的应用领域,成为了电子领域中不可或缺的重要元件。
联系人:黄河15602443498
座机:0755-33533774
邮箱:jiakedz@163.com
QQ:3080074590
地址:深圳市宝安区13区宝民一路白金大厦13F
*联系人: | 请填写您的真实姓名 |
*手机号码: | 请填写您的联系电话 |
电子邮件: | |
*采购意向描述: | |
请填写采购的产品数量和产品描述,方便我们进行统一备货。 | |
验证码: | |
我要评论: | |
内 容: | (内容最多500个汉字,1000个字符) |
验证码: | 看不清?! |
传真:0755-33533774
QQ:3080074590
邮箱:jiakedz@163.com
地址:深圳市宝安区宝民一路123号3号楼13F
共有-条评论【我要评论】
