9C08000093,8MHz晶振,49SMD晶振,TXC晶振,20PF,30PPM

产品分类：晶振规格书

订购热线： 0755-33533774

跟此产品相关的产品

: 8Q26077003,26MHz晶振,1612晶振,TXC晶振,8PF,10PPM

: 8Y16077001,16MHz晶振,2016晶振,TXC晶振,8PF,10PPM

: 8Z12070004,12MHz晶振,2520晶振,TXC晶振,12PF,10PPM

产品详情

9C03500034	3.579545MHz	±30ppm	16pF	-10°C ~ 60°C
9C03500061	3.579545MHz	±30ppm	18pF	-10°C ~ 60°C
9C03577001	3.58MHz	±20ppm	18pF	-20°C ~ 70°C
9C03600011	3.6864MHz	±30ppm	32pF	-10°C ~ 70°C
9C03600020	3.6864MHz	±50ppm	16pF	-10°C ~ 60°C
9C03600039	3.6864MHz	±50ppm	18pF	-10°C ~ 60°C
9C03600048	3.6864MHz	±30ppm	30pF	-20°C ~ 70°C
9C03600084	3.6864MHz	±50ppm	20pF	-10°C ~ 70°C
9C03600100	3.6864MHz	±50ppm	20pF	-40°C ~ 85°C
9C03600119	3.6864MHz	±30ppm	18pF	-10°C ~ 60°C
9C03600146	3.6864MHz	±30ppm	20pF	-20°C ~ 70°C
9C04000008	4MHz	±30ppm	30pF	-40°C ~ 85°C
9C04000042	4MHz	±50ppm	18pF	-40°C ~ 85°C
9C04000104	4MHz	±30ppm	30pF	-10°C ~ 60°C
9C04000131	4MHz	±30ppm	20pF	-10°C ~ 60°C
9C04000140	4MHz	±30ppm	16pF	-20°C ~ 70°C
9C04000168	4MHz	±20ppm	20pF	-10°C ~ 70°C
9C04000202	4MHz	±25ppm	12pF	-25°C ~ 85°C
9C04000239	4MHz	±50ppm	16pF	-40°C ~ 85°C
9C04070005	4MHz	±30ppm	27pF	-20°C ~ 70°C
9C04070006	4MHz	±30ppm	18pF	-20°C ~ 70°C
9C04070007	4.096MHz	±30ppm	18pF	-20°C ~ 70°C
9C04600001	4.608MHz	±20ppm	32pF	-20°C ~ 70°C
9C04900029	4.9152MHz	±30ppm	20pF	-10°C ~ 70°C
9C05100032	5.12MHz	±30ppm	30pF	-40°C ~ 85°C
9C06000002	6MHz	±30ppm	20pF	-40°C ~ 85°C
9C06000059	6MHz	±30ppm	16pF	-10°C ~ 60°C
9C06000086	6MHz	±30ppm	20pF	-20°C ~ 70°C
9C06000246	6MHz	±30ppm	16pF	-40°C ~ 85°C
9C06070008	6MHz	±30ppm	18pF	-40°C ~ 85°C
9C06100027	6.144MHz	±30ppm	16pF	-10°C ~ 70°C
9C07300003	7.3728MHz	±30ppm	20pF	-20°C ~ 70°C
9C07300012	7.3728MHz	±50ppm	32pF	-10°C ~ 60°C
9C07300021	7.3728MHz	±30ppm	30pF	-10°C ~ 60°C
9C07300076	7.3728MHz	±30ppm	30pF	-40°C ~ 85°C
9C07370004	7.3728MHz	±30ppm	18pF	-40°C ~ 85°C
9C08000001	8MHz	±30ppm	30pF	-40°C ~ 85°C
9C08000003	8MHz	±20ppm	20pF	-10°C ~ 70°C
9C08000005	8MHz	±30ppm	30pF	-40°C ~ 85°C
9C08000008	8MHz	±30ppm	18pF	-20°C ~ 70°C
9C08000012	8MHz	±10ppm	18pF	-20°C ~ 70°C
9C08000048	8MHz	±30ppm	16pF	-10°C ~ 60°C
9C08000066	8MHz	±50ppm	12pF	-10°C ~ 60°C
9C08000093	8MHz	±30ppm	20pF	-10°C ~ 60°C
9C08000119	8MHz	±50ppm	18pF	-20°C ~ 70°C
9C08000128	8MHz	±30ppm	30pF	-10°C ~ 60°C
9C08000155	8MHz	±30ppm	20pF	-10°C ~ 70°C
9C08000271	8MHz	±30ppm	12pF	-20°C ~ 70°C
9C08070004	8MHz	±30ppm	18pF	-40°C ~ 85°C
9C08076001	8MHz	±30ppm	18pF	-40°C ~ 85°C
9C08080002	8MHz	±50ppm	12pF	-10°C ~ 70°C
9C08100034	8.192MHz	±50ppm	16pF	-20°C ~ 70°C
9C08170001	8.192MHz	±50ppm	20pF	-10°C ~ 70°C
9C08600011	8.6016MHz	±30ppm	20pF	-20°C ~ 70°C
9C09800001	9.8304MHz	±30ppm	32pF	-20°C ~ 70°C
9C09800015	9.8304MHz	±50ppm	20pF	-10°C ~ 60°C
9C-10.000MAAE-T	10MHz	±30ppm	12pF	-20°C ~ 70°C
9C-10.000MAAJ-T	10MHz	±30ppm	18pF	-20°C ~ 70°C
9C-10.000MAGJ-T	10MHz	±30ppm	18pF	-40°C ~ 85°C
9C-10.000MBBK-T	10MHz	±50ppm	20pF	-20°C ~ 70°C
9C-10.000MEEJ-T	10MHz	±10ppm	18pF	-20°C ~ 70°C
9C10000067	10MHz	±30ppm	30pF	-10°C ~ 60°C
9C10000085	10MHz	±30ppm	18pF	-10°C ~ 60°C
9C10000218	10MHz	±30ppm	16pF	-40°C ~ 85°C
9C10070006	10MHz	±10ppm	18pF	-20°C ~ 70°C
9C-11.000MAAE-T	11MHz	±30ppm	12pF	-20°C ~ 70°C
9C-11.000MAAJ-T	11MHz	±30ppm	18pF	-20°C ~ 70°C
9C-11.000MBBK-T	11MHz	±50ppm	20pF	-20°C ~ 70°C
9C-11.0592MAAE-T	11.0592MHz	±30ppm	12pF	-20°C ~ 70°C
9C-11.0592MAAJ-T	11.0592MHz	±30ppm	18pF	-20°C ~ 70°C
9C-11.0592MAGJ-T	11.059MHz	±30ppm	18pF	-40°C ~ 85°C
9C-11.0592MBBK-T	11.0592MHz	±50ppm	20pF	-20°C ~ 70°C
9C-11.0592MEEJ-T	11.0592MHz	±10ppm	18pF	-20°C ~ 70°C
9C-11.2896MAAE-T	11.2896MHz	±30ppm	12pF	-20°C ~ 70°C
9C-11.2896MAAJ-T	11.2896MHz	±30ppm	18pF	-20°C ~ 70°C
9C-11.2896MBBK-T	11.2896MHz	±50ppm	20pF	-20°C ~ 70°C
9C-11.2896MEEJ-T	11.2896MHz	±10ppm	18pF	-20°C ~ 70°C
9C11000002	11.0592MHz	±30ppm	22pF	-40°C ~ 85°C
9C11000025	11.0592MHz	±30ppm	20pF	-20°C ~ 70°C
9C11000061	11.0592MHz	±30ppm	16pF	-10°C ~ 60°C
9C11230001	11.0896MHz	±30ppm	20pF	-20°C ~ 70°C
9C-12.000MAAE-T	12MHz	±30ppm	12pF	-20°C ~ 70°C
9C-12.000MAAJ-T	12MHz	±30ppm	18pF	-20°C ~ 70°C
9C-12.000MAGJ-T	12MHz	±50ppm	18pF	-40°C ~ 85°C
9C-12.000MAHK-T	12MHz	±30ppm	20pF	-40°C ~ 85°C
9C-12.000MBBK-T	12MHz	±50ppm	20pF	-20°C ~ 70°C
9C-12.000MEEJ-T	12MHz	±10ppm	18pF	-20°C ~ 70°C
9C-12.288MAAE-T	12.288MHz	±30ppm	12pF	-20°C ~ 70°C
9C-12.288MAAJ-T	12.288MHz	±30ppm	18pF	-20°C ~ 70°C
9C-12.288MBBK-T	12.288MHz	±50ppm	20pF	-20°C ~ 70°C
9C-12.288MEEJ-T	12.288MHz	±10ppm	18pF	-20°C ~ 70°C
9C-12.500MAAJ-T	12.5MHz	±30ppm	18pF	-20°C ~ 70°C
9C12000005	12MHz	±30ppm	20pF	-20°C ~ 85°C
9C12000008	12MHz	±30ppm	16pF	-40°C ~ 85°C
9C12000010	12MHz	±50ppm	32pF	-10°C ~ 60°C
9C12000065	12MHz	±30ppm	20pF	-10°C ~ 60°C
9C12000083	12MHz	±30ppm	30pF	-20°C ~ 70°C
9C12000136	12MHz	±30ppm	18pF	0°C ~ 70°C
9C12000207	12MHz	±30ppm	16pF	-10°C ~ 60°C
9C12000289	12MHz	±30ppm	18pF	-20°C ~ 70°C
9C12000430	12MHz	±10ppm	15pF	-10°C ~ 60°C
9C12000476	12MHz	±30ppm	18pF	-40°C ~ 85°C
9C12000485	12MHz	±50ppm	12pF	-10°C ~ 60°C
9C12020001	12MHz	±50ppm	18pF	-20°C ~ 70°C
9C12070007	12MHz	±30ppm	18pF	-20°C ~ 70°C
9C12076001	12MHz	±30ppm	18pF	-40°C ~ 85°C
9C12200002	12.288MHz	±50ppm	12pF	-10°C ~ 70°C
9C12200004	12.288MHz	±30ppm	20pF	-10°C ~ 70°C
9C12270001	12.288MHz	±30ppm	18pF	-20°C ~ 70°C
9C-13.0625MBBK-T	13.0625MHz	±50ppm	20pF	-20°C ~ 70°C
9C-13.225625MAAE-T	13.225625MHz	±30ppm	12pF	-20°C ~ 70°C
9C-13.225625MAAK-T	13.225MHz	±30ppm	20pF	-20°C ~ 70°C
9C-13.225625MBBK-T	13.225625MHz	±50ppm	20pF	-20°C ~ 70°C
9C-13.225625MDAE-T	13.225MHz	±30ppm	12pF	-20°C ~ 70°C
9C-13.560MAAE-T	13.56MHz	±30ppm	12pF	-20°C ~ 70°C
9C-13.560MAAJ-T	13.56MHz	±30ppm	18pF	-20°C ~ 70°C
9C-13.560MBBK-T	13.56MHz	±50ppm	20pF	-20°C ~ 70°C
9C-13.560MEEJ-T	13.56MHz	±10ppm	18pF	-20°C ~ 70°C
9C-13.824MAAJ-T	13.824MHz	±30ppm	18pF	-20°C ~ 70°C
9C-13.824MEEK-T	13.824MHz	±10ppm	20pF	-20°C ~ 70°C
9C13200023	13.225625MHz	±30ppm	20pF	-20°C ~ 70°C
9C13200041	13.225625MHz	±30ppm	20pF	-20°C ~ 70°C
9C13500108	13.56MHz	±30ppm	18pF	-10°C ~ 70°C
9C13500340	13.56MHz	±30ppm	12pF	-10°C ~ 70°C
9C13530001	13.5MHz	±15ppm	14pF	-20°C ~ 70°C
9C13800023	13.824MHz	±10ppm	18pF	-10°C ~ 70°C
9C-14.31818MAAE-T	14.31818MHz	±30ppm	12pF	-20°C ~ 70°C
9C-14.31818MAAJ-T	14.31818MHz	±30ppm	18pF	-20°C ~ 70°C
9C-14.31818MAAK-T	14.318MHz	±30ppm	20pF	-20°C ~ 70°C
9C-14.31818MBBK-T	14.31818MHz	±50ppm	20pF	-20°C ~ 70°C
9C-14.31818MEEJ-T	14.31818MHz	±10ppm	18pF	-20°C ~ 70°C
9C-14.7456MAAE-T	14.7456MHz	±30ppm	12pF	-20°C ~ 70°C
9C-14.7456MAAJ-T	14.7456MHz	±30ppm	18pF	-20°C ~ 70°C
9C-14.7456MAIJ-T	14.745MHz	±30ppm	18pF	-40°C ~ 85°C
9C-14.7456MBBK-T	14.7456MHz	±50ppm	20pF	-20°C ~ 70°C
9C-14.7456MEEJ-T	14.7456MHz	±10ppm	18pF	-20°C ~ 70°C
9C14300001	14.31818MHz	±30ppm	20pF	-20°C ~ 80°C
9C14300166	14.31818MHz	±30ppm	20pF	-10°C ~ 60°C
9C14300282	14.31818MHz	±30ppm	12pF	-10°C ~ 60°C
9C14300479	14.31818MHz	±30ppm	20pF	-10°C ~ 70°C
9C14700003	14.7456MHz	±30ppm	18pF	-20°C ~ 70°C
9C14700004	14.7456MHz	±50ppm	16pF	-40°C ~ 85°C
9C14700013	14.7456MHz	±50ppm	18pF	-10°C ~ 60°C
9C14700031	14.7456MHz	±30ppm	30pF	-10°C ~ 60°C
9C14770001	14.7456MHz	±30ppm	18pF	-20°C ~ 70°C
9C-15.000MABK-T	15MHz	±50ppm	20pF	-20°C ~ 70°C
9C-15.000MBBK-T	15MHz	±50ppm	20pF	-20°C ~ 70°C
9C-15.360MAAE-T	15.36MHz	±30ppm	12pF	-20°C ~ 70°C
9C-15.360MAAJ-T	15.36MHz	±30ppm	18pF	-20°C ~ 70°C
9C-15.360MBBK-T	15.36MHz	±50ppm	20pF	-20°C ~ 70°C
9C-15.360MEEJ-T	15.36MHz	±10ppm	18pF	-20°C ~ 70°C
9C15000211	25MHz	±20ppm	20pF	-20°C ~ 80°C
9C-16.000MAAE-T	16MHz	±30ppm	12pF	-20°C ~ 70°C
9C-16.000MAAJ-T	16MHz	±30ppm	18pF	-20°C ~ 70°C
9C-16.000MABS-T	16MHz	±50ppm	30pF	-20°C ~ 70°C
9C-16.000MAGJ-T	16MHz	±50ppm	18pF	-40°C ~ 85°C
9C-16.000MAHK-T	16MHz	±30ppm	20pF	-40°C ~ 85°C
9C-16.000MBBK-T	16MHz	±50ppm	20pF	-20°C ~ 70°C
9C-16.000MEEJ-T	16MHz	±10ppm	18pF	-20°C ~ 70°C
9C-16.000MEIJ-T	16MHz	±20ppm	18pF	-40°C ~ 85°C
9C-16.36766MBGQ-T	16.367MHz	±50ppm	10pF	-40°C ~ 85°C
9C-16.384MAAE-T	16.384MHz	±30ppm	12pF	-20°C ~ 70°C
9C-16.384MAAJ-T	16.384MHz	±30ppm	18pF	-20°C ~ 70°C
9C-16.384MBBK-T	16.384MHz	±50ppm	20pF	-20°C ~ 70°C
9C-16.384MEEJ-T	16.384MHz	±10ppm	18pF	-20°C ~ 70°C
9C-16.9344MAAE-T	16.9344MHz	±30ppm	12pF	-20°C ~ 70°C
9C-16.9344MBBK-T	16.9344MHz	±50ppm	20pF	-20°C ~ 70°C
9C16000001	16MHz	±30ppm	18pF	-40°C ~ 85°C
9C16000003	16MHz	±30ppm	16pF	-10°C ~ 60°C
9C16000009	16MHz	±50ppm	16pF	-40°C ~ 85°C
9C16000013	16MHz	±30ppm	16pF	-10°C ~ 60°C
9C16000016	16MHz	±50ppm	32pF	-10°C ~ 60°C
9C16000023	16MHz	±20ppm	16pF	-20°C ~ 90°C
9C16000043	16MHz	±50ppm	16pF	-10°C ~ 60°C
9C16000114	16MHz	±30ppm	30pF	-20°C ~ 70°C
9C16000132	16MHz	±50ppm	20pF	0°C ~ 70°C
9C16000141	16MHz	±20ppm	16pF	-40°C ~ 85°C
9C16000196	16MHz	±20ppm	系列	-40°C ~ 85°C
9C16000212	16MHz	±30ppm	20pF	-20°C ~ 80°C
9C16000285	16MHz	±50ppm	16pF	-10°C ~ 70°C
9C16000418	16MHz	±25ppm	20pF	-20°C ~ 85°C
9C16070005	16MHz	±15ppm	9pF	0°C ~ 85°C
9C16070006	16MHz	±30ppm	9pF	-10°C ~ 50°C
9C16070012	16MHz	±10ppm	18pF	-20°C ~ 70°C
9C16076001	16MHz	±30ppm	18pF	-40°C ~ 85°C
9C16300003	16.36766MHz	±50ppm	10pF	-40°C ~ 85°C
9C16370003	16.384MHz	±10ppm	18pF	-20°C ~ 70°C
9C-17.1776MAAK-T	17.177MHz	±30ppm	20pF	-20°C ~ 70°C
9C-17.1776MFHK-T	17.177MHz	±30ppm	20pF	-40°C ~ 85°C
9C-18.000MBBK-T	18MHz	±50ppm	20pF	-20°C ~ 70°C
9C-18.432MAAE-T	18.432MHz	±30ppm	12pF	-20°C ~ 70°C
9C-18.432MAAJ-T	18.432MHz	±30ppm	18pF	-20°C ~ 70°C
9C-18.432MAGK-T	18.432MHz	±30ppm	20pF	-40°C ~ 85°C
9C-18.432MAGS-T	18.432MHz	±30ppm	30pF	-40°C ~ 85°C
9C-18.432MBBK-T	18.432MHz	±50ppm	20pF	-20°C ~ 70°C
9C-18.432MEEJ-T	18.432MHz	±10ppm	18pF	-20°C ~ 70°C
9C18000014	18MHz	±30ppm	20pF	-10°C ~ 60°C
9C18400002	18.432MHz	±30ppm	12pF	-40°C ~ 85°C
9C18400003	18.432MHz	±30ppm	27pF	-10°C ~ 70°C
9C18400032	18.432MHz	±50ppm	30pF	-10°C ~ 60°C
9C18400069	18.432MHz	±30ppm	16pF	-10°C ~ 60°C
9C18400096	18.432MHz	±30ppm	18pF	-20°C ~ 70°C
9C18400158	18.432MHz	±50ppm	30pF	-40°C ~ 85°C
9C-19.200MAAE-T	19.2MHz	±30ppm	12pF	-20°C ~ 70°C
9C-19.200MAAJ-T	19.2MHz	±30ppm	18pF	-20°C ~ 70°C
9C-19.200MAAS-T	19.2MHz	±30ppm	30pF	-20°C ~ 70°C
9C-19.200MBBK-T	19.2MHz	±50ppm	20pF	-20°C ~ 70°C
9C-19.200MEEJ-T	19.2MHz	±10ppm	18pF	-20°C ~ 70°C
9C-19.6608MAAE-T	19.6608MHz	±30ppm	12pF	-20°C ~ 70°C
9C-19.6608MAAJ-T	19.6608MHz	±30ppm	18pF	-20°C ~ 70°C
9C-19.6608MAGJ-T	19.6608MHz	±50ppm	18pF	-40°C ~ 85°C
9C-19.6608MBBK-T	19.6608MHz	±50ppm	20pF	-20°C ~ 70°C
9C-19.660MBBK-T	19.66MHz	±50ppm	20pF	-20°C ~ 70°C
9C19400001	19.44MHz	±30ppm	30pF	-40°C ~ 85°C
9C19600007	19.6608MHz	±50ppm	18pF	-40°C ~ 85°C
9C19600018	19.6608MHz	±50ppm	18pF	-40°C ~ 85°C
9C19670001	19.6608MHz	±30ppm	18pF	-20°C ~ 70°C
9C19977001	19.95MHz	±30ppm	20pF	-20°C ~ 70°C
9C-20.000MAAE-T	20MHz	±30ppm	12pF	-20°C ~ 70°C
9C-20.000MAAI-T	20MHz	±30ppm	16pF	-20°C ~ 70°C
9C-20.000MAAJ-T	20MHz	±30ppm	18pF	-20°C ~ 70°C
9C-20.000MAGE-T	20MHz	±30ppm	12pF	-40°C ~ 85°C
9C-20.000MAGJ-T	20MHz	±50ppm	18pF	-40°C ~ 85°C
9C-20.000MBBK-T	20MHz	±50ppm	20pF	-20°C ~ 70°C
9C-20.000MEEJ-T	20MHz	±10ppm	18pF	-20°C ~ 70°C
9C-20.480MAAE-T	20.48MHz	±30ppm	12pF	-20°C ~ 70°C
9C-20.500MAAJ-T	20.5MHz	±30ppm	18pF	-20°C ~ 70°C
9C20000001	20MHz	±20ppm	18pF	-40°C ~ 85°C
9C20000008	20MHz	±20ppm	18pF	-40°C ~ 85°C
9C20000009	20MHz	±30ppm	12pF	-20°C ~ 70°C
9C20000015	20MHz	±30ppm	32pF	-40°C ~ 85°C
9C20000051	20MHz	±50ppm	16pF	0°C ~ 60°C
9C20000079	20MHz	±30ppm	20pF	-10°C ~ 60°C
9C20000131	20MHz	±50ppm	20pF	-20°C ~ 70°C
9C20000195	20MHz	±30ppm	30pF	-10°C ~ 60°C
9C20000211	20MHz	±50ppm	30pF	-40°C ~ 85°C
9C20000328	20MHz	±50ppm	26pF	-10°C ~ 60°C
9C20070005	20MHz	±25ppm	18pF	-10°C ~ 70°C
9C-22.000MAAE-T	22MHz	±30ppm	12pF	-20°C ~ 70°C
9C-22.000MAAJ-T	22MHz	±30ppm	18pF	-20°C ~ 70°C
9C-22.000MBBK-T	22MHz	±50ppm	20pF	-20°C ~ 70°C
9C-22.000MEEJ-T	22MHz	±10ppm	18pF	-20°C ~ 70°C
9C-22.1184MAAE-T	22.1184MHz	±30ppm	12pF	-20°C ~ 70°C
9C-22.1184MAAJ-T	22.1184MHz	±30ppm	18pF	-20°C ~ 70°C
9C-22.1184MAGK-T	22.118MHz	±30ppm	20pF	-40°C ~ 85°C
9C-22.1184MBBK-T	22.1184MHz	±50ppm	20pF	-20°C ~ 70°C
9C-22.1184MEEJ-T	22.1184MHz	±10ppm	18pF	-20°C ~ 70°C
9C-22.5792MAAJ-T	22.5792MHz	±30ppm	18pF	-20°C ~ 70°C
9C22100036	22.1184MHz	±30ppm	30pF	-10°C ~ 60°C
9C22100116	22.1184MHz	±30ppm	20pF	-20°C ~ 70°C
9C-24.000MAAE-T	24MHz	±30ppm	12pF	-20°C ~ 70°C
9C-24.000MAAJ-T	24MHz	±30ppm	18pF	-20°C ~ 70°C
9C-24.000MAGJ-T	24MHz	±50ppm	18pF	-40°C ~ 85°C
9C-24.000MBBK-T	24MHz	±50ppm	20pF	-20°C ~ 70°C
9C-24.000MDDL-T	24MHz	±20ppm	22pF	-20°C ~ 70°C
9C-24.000MEEJ-T	24MHz	±10ppm	18pF	-20°C ~ 70°C
9C-24.576MAAE-T	24.576MHz	±30ppm	12pF	-20°C ~ 70°C
9C-24.576MAAJ-T	24.576MHz	±30ppm	18pF	-20°C ~ 70°C
9C-24.576MBBK-T	24.576MHz	±50ppm	20pF	-20°C ~ 70°C
9C-24.576MEEJ-T	24.576MHz	±10ppm	18pF	-20°C ~ 70°C
9C24000002	24MHz	±30ppm	20pF	-40°C ~ 85°C
9C24000008	24MHz	±30ppm	20pF	-20°C ~ 85°C
9C24000093	24MHz	±30ppm	18pF	-20°C ~ 70°C
9C24000137	24MHz	±20ppm	12pF	-20°C ~ 70°C
9C24000146	24MHz	±30ppm	18pF	-20°C ~ 70°C
9C24020002	24MHz	±30ppm	10pF	-20°C ~ 70°C
9C24070017	24MHz	±30ppm	10pF	0°C ~ 70°C
9C24080001	24MHz	±50ppm	14.6pF	-10°C ~ 70°C
9C24500141	24.576MHz	±30ppm	30pF	-20°C ~ 70°C
9C24530001	24.576MHz	±20ppm	20pF	-10°C ~ 70°C
9C-25.000MAAE-T	25MHz	±30ppm	12pF	-20°C ~ 70°C
9C-25.000MAAJ-T	25MHz	±30ppm	18pF	-20°C ~ 70°C
9C-25.000MAAK-T	25MHz	±30ppm	20pF	-20°C ~ 70°C
9C-25.000MAGJ-T	25MHz	±50ppm	18pF	-40°C ~ 85°C
9C-25.000MAHK-T	25MHz	±30ppm	20pF	-40°C ~ 85°C
9C-25.000MBBK-T	25MHz	±50ppm	20pF	-20°C ~ 70°C
9C-25.000MBGK-T	25MHz	±50ppm	20pF	-40°C ~ 85°C
9C-25.000MEEE-T	25MHz	±30ppm	12pF	-20°C ~ 70°C
9C-25.000MEEJ-T	25MHz	±10ppm	18pF	-20°C ~ 70°C
9C-25.000MFIQ-T	25MHz	±20ppm	10pF	-40°C ~ 85°C
9C-25.600MEEJ-T	25.6MHz	±30ppm	18pF	-20°C ~ 70°C
9C25000008	25MHz	±30ppm	18pF	0°C ~ 70°C
9C25000012	25MHz	±30ppm	12pF	-40°C ~ 85°C
9C25000015	25MHz	±30ppm	18pF	-10°C ~ 60°C
9C25000051	25MHz	±25ppm	20pF	-20°C ~ 70°C
9C25000131	25MHz	±30ppm	20pF	-10°C ~ 60°C
9C25000202	25MHz	±20ppm	18pF	-40°C ~ 85°C
9C25000220	25MHz	±30ppm	20pF	-10°C ~ 70°C
9C25000248	25MHz	±20ppm	18pF	-10°C ~ 70°C
9C25000355	25MHz	±30ppm	20pF	0°C ~ 70°C
9C25000499	25MHz	±30ppm	30pF	-40°C ~ 85°C
9C25000533	25MHz	±30ppm	12pF	-10°C ~ 70°C
9C25000551	25MHz	±30ppm	20pF	0°C ~ 70°C
9C25000588	25MHz	±20ppm	12pF	0°C ~ 80°C
9C25000597	25MHz	±30ppm	12pF	-40°C ~ 85°C
9C25000677	25MHz	±50ppm	16pF	-20°C ~ 70°C
9C25000702	25MHz	±30ppm	18pF	-20°C ~ 70°C
9C25000800	25MHz	±10ppm	18pF	0°C ~ 70°C
9C25020007	25MHz	±30ppm	12pF	-20°C ~ 70°C
9C25020012	25MHz	±15ppm	18pF	-10°C ~ 70°C
9C25030004	25MHz	±20ppm	18pF	0°C ~ 70°C
9C25070001	25MHz	±50ppm	16pF	-20°C ~ 70°C
9C25070003	25MHz	±50ppm	18pF	-40°C ~ 85°C
9C25070007	25MHz	±10ppm	16pF	0°C ~ 70°C
9C25070014	25MHz	±50ppm	12pF	-20°C ~ 70°C
9C25070015	25MHz	±30ppm	20pF	-20°C ~ 70°C
9C25070016	25MHz	±30ppm	20pF	-20°C ~ 70°C
9C25070020	25MHz	±17ppm	18pF	0°C ~ 60°C
9C25070027	25MHz	±20ppm	10pF	-40°C ~ 85°C
9C25070049	25MHz	±15ppm	16pF	0°C ~ 85°C
9C25077009	25MHz	±30ppm	20pF	-20°C ~ 70°C
9C-26.000MAAE-T	26MHz	±30ppm	12pF	-20°C ~ 70°C
9C-26.000MAAJ-T	26MHz	±30ppm	18pF	-20°C ~ 70°C
9C-26.000MBBK-T	26MHz	±50ppm	20pF	-20°C ~ 70°C
9C-26.000MDDI-T	26MHz	±20ppm	16pF	-20°C ~ 70°C
9C-26.000MEEJ-T	26MHz	±10ppm	18pF	-20°C ~ 70°C
9C-27.000MAAE-T	27MHz	±30ppm	12pF	-20°C ~ 70°C
9C-27.000MAAJ-T	27MHz	±30ppm	18pF	-20°C ~ 70°C
9C-27.000MAAK-T	27MHz	±30ppm	20pF	-20°C ~ 70°C
9C-27.000MBBK-T	27MHz	±50ppm	20pF	-20°C ~ 70°C
9C-27.000MDDI-T	27MHz	±20ppm	16pF	-20°C ~ 70°C
9C-27.000MEEJ-T	27MHz	±10ppm	18pF	-20°C ~ 70°C
9C-27.120MAAJ-T	27.12MHz	±30ppm	18pF	-20°C ~ 70°C
9C27000006	27MHz	±30ppm	16pF	-20°C ~ 85°C
9C27000010	27MHz	±30ppm	20pF	-20°C ~ 85°C
9C27000021	27MHz	±20ppm	20pF	-20°C ~ 85°C
9C27000157	27MHz	±50ppm	18pF	0°C ~ 70°C
9C27070005	27MHz	±30ppm	18pF	-20°C ~ 70°C
9C27070014	27MHz	±10ppm	18pF	-20°C ~ 70°C
9C27070015	27MHz	±30ppm	14.5pF	0°C ~ 85°C
9C27070020	27MHz	±15ppm	18pF	0°C ~ 70°C
9C-28.224MAAJ-T	28.224MHz	±30ppm	18pF	-20°C ~ 70°C
9C-28.322MAAJ-T	28.322MHz	±30ppm	18pF	-20°C ~ 70°C
9C-28.322MBBK-T	28.322MHz	±50ppm	20pF	-20°C ~ 70°C
9C-28.63636MAAE-T	28.63636MHz	±30ppm	12pF	-20°C ~ 70°C
9C-28.63636MAAJ-T	28.63636MHz	±30ppm	18pF	-20°C ~ 70°C
9C-28.63636MBBK-T	28.63636MHz	±50ppm	20pF	-20°C ~ 70°C
9C-28.63636MEEJ-T	28.63636MHz	±10ppm	18pF	-20°C ~ 70°C
9C-28.800MBBK-T	28.8MHz	±50ppm	20pF	-20°C ~ 70°C
9C-3.579545MAAE-T	3.579545MHz	±30ppm	12pF	-20°C ~ 70°C
9C-3.579545MAAJ-T	3.579545MHz	±30ppm	18pF	-20°C ~ 70°C
9C-3.579545MBBK-T	3.579545MHz	±50ppm	20pF	-20°C ~ 70°C
9C-3.6864MAAE-T	3.6864MHz	±30ppm	12pF	-20°C ~ 70°C
9C-3.6864MAAJ-T	3.6864MHz	±30ppm	18pF	-20°C ~ 70°C
9C-3.6864MAAS-T	3.6864MHz	±30ppm	30pF	-20°C ~ 70°C
9C-3.6864MAGJ-T	3.6864MHz	±30ppm	18pF	-40°C ~ 85°C
9C-3.6864MBBK-T	3.6864MHz	±50ppm	20pF	-20°C ~ 70°C
9C-30.000MAAE-T	30MHz	±30ppm	12pF	-20°C ~ 70°C
9C-30.000MAAJ-T	30MHz	±30ppm	18pF	-20°C ~ 70°C
9C-30.000MBBK-T	30MHz	±50ppm	20pF	-20°C ~ 70°C
9C-30.000MEEJ-T	30MHz	±10ppm	18pF	-20°C ~ 70°C
9C30000007	30MHz	±30ppm	20pF	-10°C ~ 85°C
9C30000008	30MHz	±20ppm	20pF	-20°C ~ 70°C
9C30000198	30MHz	±20ppm	12pF	-10°C ~ 70°C
9C-31.250MBBK-T	31.25MHz	±50ppm	20pF	-20°C ~ 70°C
9C-31.875MAAJ-T	31.875MHz	±30ppm	18pF	-20°C ~ 70°C
9C-32.000MAAE-T	32MHz	±30ppm	12pF	-20°C ~ 70°C
9C-32.000MAAJ-T	32MHz	±30ppm	18pF	-20°C ~ 70°C
9C-32.000MBBK-T	32MHz	±50ppm	20pF	-20°C ~ 70°C
9C32070003	32MHz	±10ppm	18pF	-10°C ~ 70°C
9C-33.3330MAAJ-T	33.333MHz	±30ppm	18pF	-20°C ~ 70°C
9C-35.328MAAE-T	35.328MHz	±30ppm	12pF	-20°C ~ 70°C
9C-35.328MAAJ-T	35.328MHz	±30ppm	18pF	-20°C ~ 70°C
9C-35.328MBBK-T	35.328MHz	±50ppm	20pF	-20°C ~ 70°C
9C-35.328MEEJ-T	35.328MHz	±10ppm	18pF	-20°C ~ 70°C
9C-35.840MAAJ-T	35.84MHz	±30ppm	18pF	-20°C ~ 70°C
9C35800081	35.84MHz	±30ppm	18pF	0°C ~ 85°C
9C-36.000MAAE-T	36MHz	±30ppm	12pF	-20°C ~ 70°C
9C-36.000MAAJ-T	36MHz	±30ppm	18pF	-20°C ~ 70°C
9C-36.000MBBK-T	36MHz	±50ppm	20pF	-20°C ~ 70°C
9C-36.000MEEJ-T	36MHz	±10ppm	18pF	-20°C ~ 70°C
9C-37.500MAAE-T	37.5MHz	±30ppm	12pF	-20°C ~ 70°C
9C-37.500MEEE-T	37.5MHz	±30ppm	12pF	-20°C ~ 70°C
9C-4.000MAAE-T	4MHz	±30ppm	12pF	-20°C ~ 70°C
9C-4.000MAAJ-T	4MHz	±30ppm	18pF	-20°C ~ 70°C
9C-4.000MAGJ-T	4MHz	±50ppm	18pF	-40°C ~ 85°C
9C-4.000MBBK-T	4MHz	±50ppm	20pF	-20°C ~ 70°C
9C-4.096MAAE-T	4.096MHz	±30ppm	12pF	-20°C ~ 70°C
9C-4.096MAAJ-T	4.096MHz	±30ppm	18pF	-20°C ~ 70°C
9C-4.096MBBK-T	4.096MHz	±50ppm	20pF	-20°C ~ 70°C
9C-4.194304MAAJ-T	4.194304MHz	±30ppm	18pF	-20°C ~ 70°C
9C-4.194304MAHK-T	4.1943MHz	±30ppm	20pF	-40°C ~ 85°C
9C-4.194304MBBK-T	4.194304MHz	±50ppm	20pF	-20°C ~ 70°C
9C-4.433619MBBK-T	4.433619MHz	±50ppm	20pF	-20°C ~ 70°C
9C-4.9152MAAE-T	4.9152MHz	±30ppm	12pF	-20°C ~ 70°C
9C-4.9152MAAJ-T	4.9152MHz	±30ppm	18pF	-20°C ~ 70°C
9C-4.9152MAAK-T	4.9152MHz	±30ppm	20pF	-20°C ~ 70°C
9C-4.9152MAHK-T	4.9152MHz	±30ppm	20pF	-40°C ~ 85°C
9C-4.9152MBBK-T	4.9152MHz	±50ppm	20pF	-20°C ~ 70°C
9C-48.000MAAE-T	48MHz	±30ppm	12pF	-20°C ~ 70°C
9C-48.000MAAJ-T	48MHz	±30ppm	18pF	-20°C ~ 70°C
9C-48.000MBBK-T	48MHz	±50ppm	20pF	-20°C ~ 70°C
9C-48.000MEEJ-T	48MHz	±10ppm	18pF	-20°C ~ 70°C
9C48000077	48MHz	±30ppm	20pF	-40°C ~ 85°C
9C48000086	48MHz	±30ppm	18pF	-20°C ~ 85°C
9C-5.000MAAE-T	5MHz	±30ppm	12pF	-20°C ~ 70°C
9C-5.000MAAJ-T	5MHz	±30ppm	18pF	-20°C ~ 70°C
9C-5.000MBBK-T	5MHz	±50ppm	20pF	-20°C ~ 70°C
9C-5.0688MAAE-T	5.0688MHz	±30ppm	12pF	-20°C ~ 70°C
9C-5.0688MAAJ-T	5.0688MHz	±30ppm	18pF	-20°C ~ 70°C
9C-5.0688MBBK-T	5.0688MHz	±50ppm	20pF	-20°C ~ 70°C
9C-50.000MAAE-T	50MHz	±30ppm	12pF	-20°C ~ 70°C
9C-50.000MAAJ-T	50MHz	±30ppm	18pF	-20°C ~ 70°C
9C-50.000MBBK-T	50MHz	±50ppm	20pF	-20°C ~ 70°C
9C-50.000MEEJ-T	50MHz	±10ppm	18pF	-20°C ~ 70°C
9C50070001	50MHz	±20ppm	10pF	-40°C ~ 85°C
9C-54.000MAAE-T	54MHz	±30ppm	12pF	-20°C ~ 70°C
9C-54.000MAAJ-T	54MHz	±30ppm	18pF	-20°C ~ 70°C
9C-54.000MBBK-T	54MHz	±50ppm	20pF	-20°C ~ 70°C
9C54090001	54MHz	±15ppm	10pF	-20°C ~ 70°C
9C-6.000MAAE-T	6MHz	±30ppm	12pF	-20°C ~ 70°C
9C-6.000MAAJ-T	6MHz	±30ppm	18pF	-20°C ~ 70°C
9C-6.000MBBK-T	6MHz	±50ppm	20pF	-20°C ~ 70°C
9C-6.144MAAE-T	6.144MHz	±30ppm	12pF	-20°C ~ 70°C
9C-6.144MAAJ-T	6.144MHz	±30ppm	18pF	-20°C ~ 70°C
9C-6.144MBBK-T	6.144MHz	±50ppm	20pF	-20°C ~ 70°C
9C-6.500MAAJ-T	6.5MHz	±30ppm	18pF	-20°C ~ 70°C
9C-6.78881MEEK-T	6.7888MHz	±30ppm	20pF	-20°C ~ 70°C
9C-60.000MAAE-T	60MHz	±30ppm	12pF	-20°C ~ 70°C
9C-60.000MAAJ-T	60MHz	±30ppm	18pF	-20°C ~ 70°C
9C-60.000MBBK-T	60MHz	±50ppm	20pF	-20°C ~ 70°C
9C-64.000MAAE-T	64MHz	±30ppm	12pF	-20°C ~ 70°C
9C-64.000MAAJ-T	64MHz	±30ppm	18pF	-20°C ~ 70°C
9C-64.000MAGJ-T	64MHz	±30ppm	18pF	-40°C ~ 85°C
9C-64.000MBBK-T	64MHz	±50ppm	20pF	-20°C ~ 70°C
9C64000001	64MHz	±25ppm	18pF	-40°C ~ 85°C
9C-7.3728MAAE-T	7.3728MHz	±30ppm	12pF	-20°C ~ 70°C
9C-7.3728MAAJ-T	7.3728MHz	±30ppm	18pF	-20°C ~ 70°C
9C-7.3728MBBK-T	7.3728MHz	±50ppm	20pF	-20°C ~ 70°C
9C-7.392MCFK-T	7.392MHz	±100ppm	20pF	-40°C ~ 85°C
9C-7.680MAAE-T	7.68MHz	±30ppm	12pF	-20°C ~ 70°C
9C-7.680MAAJ-T	7.68MHz	±30ppm	18pF	-20°C ~ 70°C
9C-7.680MBBK-T	7.68MHz	±50ppm	20pF	-20°C ~ 70°C
9C-8.000MAAE-T	8MHz	±30ppm	12pF	-20°C ~ 70°C
9C-8.000MAAJ-T	8MHz	±30ppm	18pF	-20°C ~ 70°C
9C-8.000MAAL-T	8MHz	±30ppm	22pF	-20°C ~ 70°C
9C-8.000MAAS-T	8MHz	±30ppm	30pF	-20°C ~ 70°C
9C-8.000MABK-T	8MHz	±50ppm	20pF	-20°C ~ 70°C
9C-8.000MAGJ-T	8MHz	±50ppm	18pF	-40°C ~ 85°C
9C-8.000MAHK-T	8MHz	±30ppm	20pF	-40°C ~ 85°C
9C-8.000MBBK-T	8MHz	±50ppm	20pF	-20°C ~ 70°C
9C-8.000MEEE-T	8MHz	±30ppm	12pF	-20°C ~ 70°C
9C-8.000MEEJ-T	8MHz	±10ppm	18pF	-20°C ~ 70°C
9C-8.192MAAE-T	8.192MHz	±30ppm	12pF	-20°C ~ 70°C
9C-8.192MAAJ-T	8.192MHz	±30ppm	18pF	-20°C ~ 70°C
9C-8.192MAHJ-T	8.192MHz	±30ppm	18pF	-40°C ~ 85°C
9C-8.192MBBK-T	8.192MHz	±50ppm	20pF	-20°C ~ 70°C
9C-8.192MEEJ-T	8.192MHz	±10ppm	18pF	-20°C ~ 70°C
9C-8.4672MBBK-T	8.4672MHz	±50ppm	20pF	-20°C ~ 70°C
9C-8.912MAAE-T	8.912MHz	±30ppm	12pF	-20°C ~ 70°C
9C-8.912MAAJ-T	8.912MHz	±30ppm	18pF	-20°C ~ 70°C
9C-8.912MAHJ-T	8.912MHz	±30ppm	18pF	-40°C ~ 85°C
9C-8.912MBBK-T	8.912MHz	±50ppm	20pF	-20°C ~ 70°C
9C-9.84375MBGQ-T	9.8437MHz	±50ppm	10pF	-40°C ~ 85°C

TXC晶振产品分类

爆款产品

热销品牌

查看更多品牌

新闻推荐

1：TXC晶振成为许多重要设备的不二之选

在电子行业界,台湾TXC晶振公司是一家备受瞩目的晶振制造商,其所生产的在市场上备受青睐,具备多种优势,本文将介绍TXC热销型号及其优势,帮助读者更好地了解该公司的产品。

2：TXC晶振打造每个电子系统的心跳

在当今的科技世界中,精准的时间控制已成为各种电子设备正常运行的关键因素,无论是计算机,通信设,航空航天,还是物联网,智能家居等领域,都需要高精度,高稳定的时钟信号来支撑,在这些设备中,TXC晶振作为重要的时钟源,以其卓越的性能和广泛的应用,赢得了业界的广泛赞誉.

3：「A308000001车规晶振」+「汽车应用」的完美绝配

车载电子系统的正常运行依赖于精准的时钟信号,时钟信号在车载电子系统中用于同步各个模块的工作,保证数据的可靠传输和处理,汽车内部各种功能模块（如发动机控制、车载音响、导航系统等）都需要依靠时钟信号来实现精确的时间计算和频率控制,因此选择一款可靠的车规晶振对汽车电子系统至关重要.

4：AV16070003晶振车载设备系统最重要的角色

随着车辆电子化的发展,车载电子设备的数量和功能不断增加,因此对于时钟系统的要求也越来越高,而晶振作为时钟系统的核心,必须能够提供高精度的时钟信号,以确保各个系统的协调运行,TXC晶振是全球最大的生厂商,旗下的AV16070003贴片晶振非常适用于车载系统应用.

5：AA08000016 AA08000006晶振通信设备的首选之一

在电子产业领域晶振作为电子设备中重要的稳定时钟源,对于各类智能电子设备的正常工作起到了至关重要的作用,TXC晶振作为一家在晶振领域具有丰富经验和先进技术的公司其AA08000016晶振和AA08000006晶振成为了市场上备受瞩目的产品之一,AA08000016 和AA08000006晶振独特的设计使得其尺寸小巧.

6：8P26070004温补晶振为GPS定位系统应运而生

GPS定位是一种广泛应用于各个领域的卫星导航系统,其精准定位效果对于许多应用场景至关重要,而GPS定位的精准度则与其晶振的稳定性密不可分,26MHz温补TCXO晶振是GPS信号产生的关键一部分,26MHz温补TCXO晶振负责稳定GPS信号的频率和时间,在GPS应用中为了增强GPS定位的准确性.

7：8Q32070017晶振蓝牙通讯设备的关键角色

在电子设备的内部,有一个不起眼的小部件,它默默无闻地扮演着"时间管理员"的角色,这个部件就是晶振,8Q32070017台湾晶技32MHz晶振是一款在蓝牙主板上常用的一款主流晶振,此款8Q32070017晶振负载电容10PF,10PPM,而且这款32MHz晶振更是成为现代无线通信技术的核心组件.

8：移动通讯市场最火的"8Y40000023晶振"

台湾晶技公司TXC晶振产品在近年来逐渐受到全球市场的关注,这些高精度,高稳定性的频率控制组件在通讯,物联网,智能穿戴和车载电子等领域的应用越来越广泛,今天加科电子将深入探讨TXC晶振的特点和应用,以更好地了解这一重要的电子元器件.

9：OZ26030001热敏晶振火爆出圈,开启移动通讯设备新路径

在电子设备中频率控制组件对于精确计时和稳定运行至关重要,其中TXC热敏晶振以其卓越的性能和广泛的应用,扮演着关键的角色,TXC热敏晶振是一种高精度,高稳定的贴片晶振,其基本结构包括石英晶体和热敏电阻,当温度变化时,热敏电阻的电阻值会发生变化,从而改变石英晶体的频率,这种独特的结构使得TXC热敏晶振具有高度可靠性和稳定性.

查看更多新闻

TXC晶技简介

TXC晶振在电路设计中扮演着重要的角色,它们在电子设备中随处可见,在电路中TXC晶振能够以精确的频率输出稳定的信号,使得整个电路保持同步并精确转换信号,无论是在通讯,工业控制,图像处理,数字音乐播放器,数码相机等领域,都有TXC晶振身影,TXC晶振还具有更高的稳定性和精度,能够实现更准确的计时和频率控制,此外TXC晶振还可以根据不同应用场景的需求进行定制,例如温度范围,频率,尺寸等方面,总之TXC晶振是一家高性能,定制化程度高的频率元器件厂商,其在现代科技中扮演着重要的角色,TXC现货商品的产品介绍和图片,请浏览我们的网站www.smdxtal.com/。

联系人：黄河_15602443498

座机：_{0755-33533774}

邮箱：_{jiakedz@163.com}

QQ：_3080074590

_地址：_{深圳市宝安区13区宝民一路白金大厦13F}

_网址：_{//www.michaelogg.com}

9C08000093 8MHz晶振 49SMD晶振 TXC晶振 20PF 30PPM

*表示必填 采购：9C08000093,8MHz晶振,49SMD晶振,TXC晶振,20PF,30PPM

*联系人：	请填写您的真实姓名
公司名称：	请填写您的公司名称
联系电话：
*手机号码：	请填写您的联系电话
电子邮件：
联系地址：
*采购意向描述：
	请填写采购的产品数量和产品描述,方便我们进行统一备货。
验证码：
