72MHz有源晶振,X1G004801007100,SG2016CAN,爱普生正品

产品分类：晶振规格书

特征：频率范围20标准频率,电源电压1.8V至3.3V（典型值）。功能备用（ST）外形尺寸2×1.6× 0.7毫米工作温度-40°C至+105°C。

订购热线： 0755-33533774

跟此产品相关的产品

产品详情

型号	料号	尺寸	电压	频率
SG2016CAN	X1G004801007300	2.0 x 1.6x0.7mm	2.25V-3.63V	72MHz
SG2016CAN	X1G004801007200	2.0 x 1.6x0.7mm	1.71V-3.63V	72MHz
SG2016CAN	X1G004801007100	2.0 x 1.6x0.7mm	1.71V-3.63V	72MHz
SG2016CAN	X1G004801007000	2.0 x 1.6x0.7mm	1.62V-3.63V	50MHz
SG2016CAN	X1G004801006900	2.0 x 1.6x0.7mm	1.62V-3.63V	48MHz
SG2016CAN	X1G004801006800	2.0 x 1.6x0.7mm	1.62V-3.63V	48MHz
SG2016CAN	X1G004801006700	2.0 x 1.6x0.7mm	1.62V-3.63V	40MHz
SG2016CAN	X1G004801006600	2.0 x 1.6x0.7mm	1.62V-3.63V	33.3333MHz
SG2016CAN	X1G004801006500	2.0 x 1.6x0.7mm	1.62V-3.63V	33.33MHz
SG2016CAN	X1G004801006400	2.0 x 1.6x0.7mm	1.62V-3.63V	33.33MHz
SG2016CAN	X1G004801006300	2.0 x 1.6x0.7mm	1.62V-3.63V	32MHz
SG2016CAN	X1G004801006200	2.0 x 1.6x0.7mm	1.62V-3.63V	32MHz
SG2016CAN	X1G004801006100	2.0 x 1.6x0.7mm	1.62V-3.63V	27MHz
SG2016CAN	X1G004801006000	2.0 x 1.6x0.7mm	1.62V-3.63V	24.576MHz
SG2016CAN	X1G004801005900	2.0 x 1.6x0.7mm	1.62V-3.63V	24MHz
SG2016CAN	X1G004801005800	2.0 x 1.6x0.7mm	1.62V-3.63V	20MHz
SG2016CAN	X1G004801005700	2.0 x 1.6x0.7mm	1.62V-3.63V	20MHz
SG2016CAN	X1G004801005600	2.0 x 1.6x0.7mm	1.62V-3.63V	16MHz
SG2016CAN	X1G004801005500	2.0 x 1.6x0.7mm	1.62V-3.63V	14.7456MHz
SG2016CAN	X1G004801005400	2.0 x 1.6x0.7mm	1.62V-3.63V	14.7456MHz
SG2016CAN	X1G004801005300	2.0 x 1.6x0.7mm	1.62V-3.63V	12.288MHz
SG2016CAN	X1G004801005200	2.0 x 1.6x0.7mm	1.62V-3.63V	12.288MHz
SG2016CAN	X1G004801005100	2.0 x 1.6x0.7mm	1.62V-3.63V	12MHz
SG2016CAN	X1G004801005000	2.0 x 1.6x0.7mm	1.62V-3.63V	12MHz
SG2016CAN	X1G004801004900	2.0 x 1.6x0.7mm	1.62V-3.63V	4MHz
SG2016CAN	X1G004801004600	2.0 x 1.6x0.7mm	1.62V-3.63V	8MHz
SG2016CAN	X1G004801004500	2.0 x 1.6x0.7mm	1.62V-3.63V	8MHz
SG2016CAN	X1G004801004400	2.0 x 1.6x0.7mm	1.62V-3.63V	12.288MHz
SG2016CAN	X1G004801004000	2.0 x 1.6x0.7mm	1.62V-3.63V	24MHz
SG2016CAN	X1G004801003900	2.0 x 1.6x0.7mm	1.62V-3.63V	26MHz
SG2016CAN	X1G004801003600	2.0 x 1.6x0.7mm	1.62V-3.63V	40MHz
SG2016CAN	X1G004801003500	2.0 x 1.6x0.7mm	1.62V-3.63V	25MHz
SG2016CAN	X1G004801003100	2.0 x 1.6x0.7mm	1.62V-3.63V	24.576MHz
SG2016CAN	X1G004801003000	2.0 x 1.6x0.7mm	1.62V-3.63V	4MHz
SG2016CAN	X1G004801002900	2.0 x 1.6x0.7mm	1.62V-3.63V	10MHz
SG2016CAN	X1G004801002800	2.0 x 1.6x0.7mm	1.62V-3.63V	50MHz
SG2016CAN	X1G004801002700	2.0 x 1.6x0.7mm	1.62V-3.63V	10MHz
SG2016CAN	X1G004801002600	2.0 x 1.6x0.7mm	1.62V-3.63V	33.3333MHz
SG2016CAN	X1G0048010024000	2.0 x 1.6x0.7mm	1.62V-3.63V	25MHz
SG2016CAN	X1G004801002100	2.0 x 1.6x0.7mm	1.62V-3.63V	27MHz
SG2016CAN	X1G004801002000	2.0 x 1.6x0.7mm	1.62V-3.63V	48MHz
SG2016CAN	X1G004801001800	2.0 x 1.6x0.7mm	1.62V-3.63V	20MHz
SG2016CAN	X1G004801001400	2.0 x 1.6x0.7mm	1.62V-3.63V	16MHz
SG2016CAN	X1G004801001300	2.0 x 1.6x0.7mm	1.62V-3.63V	50MHz
SG2016CAN	X1G004801001200	2.0 x 1.6x0.7mm	1.62V-3.63V	25MHz
SG2016CAN	X1G004801000700	2.0 x 1.6x0.7mm	1.62V-3.63V	12MHz
SG2016CAN	X1G004801000300	2.0 x 1.6x0.7mm	1.62V-3.63V	26MHz
SG2016CAN	X1G004801000200	2.0 x 1.6x0.7mm	1.62V-3.63V	24MHz
