40MHz晶振,1612,7PF,10PPM,ABM12W-40.0000MHZ-8-D1X-T3,ABRACON晶振
prev next
查看全部大图

40MHz晶振,1612,7PF,10PPM,ABM12W-40.0000MHZ-8-D1X-T3,ABRACON晶振

产品分类： 晶振规格书
    订购热线： 0755-33533774
    跟此产品相关的产品
    产品详情

      料号 频率 精度 负载电容 工作温度
      ABM12-32.000MHZ-B2X-T3 32MHz ±20ppm 8pF -20°C ~ 70°C
      ABM12-117-27.120MHZ-T3 27.12MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12-115-26.000MHZ-T3 26MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12-26.000MHZ-B2X-T3 26MHz ±20ppm 8pF -20°C ~ 70°C
      ABM12-30.000MHZ-B2X-T3 30MHz ±20ppm 8pF -20°C ~ 70°C
      ABM12-40.000MHZ-B2X-T3 40MHz ±20ppm 8pF -20°C ~ 70°C
      ABM12-48.000MHZ-B2X-T3 48MHz ±20ppm 8pF -20°C ~ 70°C
      ABM12-27.000MHZ-B2X-T3 27MHz ±20ppm 8pF -20°C ~ 70°C
      ABM12-26.000MHZ-9-R100-B1U-T 26MHz ±10ppm 9pF -20°C ~ 70°C
      ABM12-116-26.000MHZ-T3 26MHz ±30ppm 8pF -40°C ~ 85°C
      ABM12-118-27.120MHZ-T3 27.12MHz ±30ppm 8pF -40°C ~ 85°C
      ABM12-36.000MHZ-B2X-T3 36MHz ±20ppm 8pF -20°C ~ 70°C
      ABM12-44.000MHZ-B2X-T3 44MHz ±20ppm 8pF -20°C ~ 70°C
      ABM12-28.63636MHZ-B2X-T3 28.63636MHz ±20ppm 8pF -20°C ~ 70°C
      ABM12AIG-50.000MHZ-1Z-T 50MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12AIG-27.000MHZ-1Z-T 27MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12AIG-32.000MHZ-6-D1X-T 32MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12AIG-32.000MHZ-1Z-T 32MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12AIG-24.000MHZ-10-1Z-T 24MHz ±50ppm 10pF -40°C ~ 125°C
      ABM12AIG-25.000MHZ-10-1Z-T 25MHz ±50ppm 10pF -40°C ~ 125°C
      ABM12AIG-27.120MHZ-10-4Z-T 27.12MHz ±50ppm 10pF -40°C ~ 125°C
      ABM12W-24.0000MHZ-8-D1X-T3 24MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-25.0000MHZ-8-D1X-T3 25MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-32.0000MHZ-8-B1U-T3 32MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-40.0000MHZ-6-B1U-T3 40MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-48.0000MHZ-8-B1U-T3 48MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-25.0000MHZ-8-B1U-T3 25MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-32.0000MHZ-6-B1U-T3 32MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-24.0000MHZ-7-D1X-T3 24MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-25.0000MHZ-6-B1U-T3 25MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-32.0000MHZ-8-D1X-T3 32MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-32.0000MHZ-4-D1X-T3 32MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-38.4000MHZ-4-D1X-T3 38.4MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-25.0000MHZ-4-D1X-T3 25MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-40.0000MHZ-8-B1U-T3 40MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-24.0000MHZ-6-B1U-T3 24MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-36.0000MHZ-6-B1U-T3 36MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-30.0000MHZ-6-D1X-T3 30MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-30.0000MHZ-7-B1U-T3 30MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-40.0000MHZ-8-D1X-T3 40MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-26.0000MHZ-6-D1X-T3 26MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-27.1200MHZ-7-B1U-T3 27.12MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-30.0000MHZ-8-B1U-T3 30MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-30.0000MHZ-7-D1X-T3 30MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-30.0000MHZ-8-D1X-T3 30MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-36.0000MHZ-8-D1X-T3 36MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-27.0000MHZ-8-D1X-T3 27MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-27.0000MHZ-8-B1U-T3 27MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-26.0000MHZ-8-D1X-T3 26MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-25.0000MHZ-7-D1X-T3 25MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-24.0000MHZ-7-B1U-T3 24MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-48.0000MHZ-7-B1U-T3 48MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-24.0000MHZ-6-D1X-T3 24MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-48.0000MHZ-6-B1U-T3 48MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-26.0000MHZ-7-D1X-T3 26MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-24.0000MHZ-8-B1U-T3 24MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-25.0000MHZ-7-B1U-T3 25MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-36.0000MHZ-8-B1U-T3 36MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-27.1200MHZ-6-D1X-T3 27.12MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-27.1200MHZ-4-D1X-T3 27.12MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-32.0000MHZ-8-J1Z-T3 32MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-24.5760MHZ-8-D1X-T3 24.576MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-32.0000MHZ-8-R80-D2X-T3 32MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-27.1200MHZ-8-D1X-T3 27.12MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-25.0000MHZ-6-D1X-T3 25MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-26.0000MHZ-7-B1U-T3 26MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-26.0000MHZ-8-B1U-T3 26MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-27.1200MHZ-6-B1U-T3 27.12MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-25.0000MHZ-6-K2Z-T3 25MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-26.0000MHZ-6-B1U-T3 26MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-27.0000MHZ-6-B1U-T3 27MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-27.0000MHZ-6-D1X-T3 27MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-27.0000MHZ-7-B1U-T3 27MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-27.0000MHZ-7-D1X-T3 27MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-27.1200MHZ-7-D1X-T3 27.12MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-27.1200MHZ-8-B1U-T3 27.12MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-30.0000MHZ-6-B1U-T3 30MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-32.0000MHZ-6-D1X-T3 32MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-32.0000MHZ-7-B1U-T3 32MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-32.0000MHZ-7-D1X-T3 32MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-36.0000MHZ-6-D1X-T3 36MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-36.0000MHZ-7-B1U-T3 36MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-36.0000MHZ-7-D1X-T3 36MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-40.0000MHZ-6-D1X-T3 40MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-40.0000MHZ-7-B1U-T3 40MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-40.0000MHZ-7-D1X-T3 40MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-48.0000MHZ-6-D1X-T3 48MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-48.0000MHZ-7-D1X-T3 48MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-48.0000MHZ-8-D1X-T3 48MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-26.0000MHZ-4-B1U-T3 26MHz ±10ppm 4pF -20°C ~ 70°C
      ABM12W-37.4000MHZ-4-D1X-T3 37.4MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-24.0000MHZ-8-D2X-T3 24MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-27.1200MHZ-8-K1Z-T3 27.12MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-32.0000MHZ-6-D2X-T3 32MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-32.0000MHZ-8-B2U-T3 32MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-32.0000MHZ-8-D2X-T3 32MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-32.0000MHZ-8-K1Z-T3 32MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-32.0000MHZ-8-K2Z-T3 32MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-33.3300MHZ-8-D1X-T3 33.33MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-33.3333MHZ-7-B1U-T3 33.3333MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-37.4000MHZ-7-D1X-T3 37.4MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-37.4000MHZ-8-D1X-T3 37.4MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-38.0000MHZ-8-D2X-T3 38MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-38.4000MHZ-8-D1X-T3 38.4MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-38.4000MHZ-8-D2X-T3 38.4MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-40.0000MHZ-8-B2U-T3 40MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-40.0000MHZ-8-D2X-T3 40MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-48.0000MHZ-8-D2X-T3 48MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-30.0000MHZ-4-D2X-T3 30MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-32.0000MHZ-4-D2X-T3 32MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-27.0000MHZ-4-B1U-T3 27MHz ±10ppm 4pF -20°C ~ 70°C
      ABM12W-26.0000MHZ-8-R100-B1U-T3 26MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-32.0000MHZ-8-R80-B1U-T3 32MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-24.0000MHZ-4-D1X-T3 24MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-24.0000MHZ-4-D2X-T3 24MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-24.0000MHZ-6-B2U-T3 24MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-24.0000MHZ-6-D2X-T3 24MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-24.0000MHZ-6-J1Z-T3 24MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-24.0000MHZ-6-J2Z-T3 24MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-24.0000MHZ-6-K1Z-T3 24MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-24.0000MHZ-6-K2Z-T3 24MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-24.0000MHZ-7-B2U-T3 24MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-24.0000MHZ-7-D2X-T3 24MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-24.0000MHZ-7-J1Z-T3 24MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-24.0000MHZ-7-J2Z-T3 24MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-24.0000MHZ-7-K1Z-T3 24MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-24.0000MHZ-7-K2Z-T3 24MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-24.0000MHZ-8-B2U-T3 24MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-24.0000MHZ-8-J1Z-T3 24MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-24.0000MHZ-8-J2Z-T3 24MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-24.0000MHZ-8-K1Z-T3 24MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-24.0000MHZ-8-K2Z-T3 24MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-24.3050MHZ-4-D1X-T3 24.305MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-24.3050MHZ-4-D2X-T3 24.305MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-24.5454MHZ-4-D1X-T3 24.5454MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-24.5454MHZ-4-D2X-T3 24.5454MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-24.5454MHZ-6-B1U-T3 24.5454MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-24.5454MHZ-6-B2U-T3 24.5454MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-24.5454MHZ-6-D1X-T3 24.5454MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-24.5454MHZ-6-D2X-T3 24.5454MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-24.5454MHZ-6-J1Z-T3 24.5454MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-24.5454MHZ-6-J2Z-T3 24.5454MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-24.5454MHZ-6-K1Z-T3 24.5454MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-24.5454MHZ-6-K2Z-T3 24.5454MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-24.5454MHZ-7-B1U-T3 24.5454MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-24.5454MHZ-7-B2U-T3 24.5454MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-24.5454MHZ-7-D1X-T3 24.5454MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-24.5454MHZ-7-D2X-T3 24.5454MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-24.5454MHZ-7-J1Z-T3 24.5454MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-24.5454MHZ-7-J2Z-T3 24.5454MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-24.5454MHZ-7-K1Z-T3 24.5454MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-24.5454MHZ-7-K2Z-T3 24.5454MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-24.5454MHZ-8-B1U-T3 24.5454MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-24.5454MHZ-8-B2U-T3 24.5454MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-24.5454MHZ-8-D1X-T3 24.5454MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-24.5454MHZ-8-D2X-T3 24.5454MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-24.5454MHZ-8-J1Z-T3 24.5454MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-24.5454MHZ-8-J2Z-T3 24.5454MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-24.5454MHZ-8-K1Z-T3 24.5454MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-24.5454MHZ-8-K2Z-T3 24.5454MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-24.5455MHZ-4-D1X-T3 24.5455MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-24.5455MHZ-4-D2X-T3 24.5455MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-24.5455MHZ-6-B1U-T3 24.5455MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-24.5455MHZ-6-B2U-T3 24.5455MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-24.5455MHZ-6-D1X-T3 24.5455MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-24.5455MHZ-6-D2X-T3 24.5455MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-24.5455MHZ-6-J1Z-T3 24.5455MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-24.5455MHZ-6-J2Z-T3 24.5455MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-24.5455MHZ-6-K1Z-T3 24.5455MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-24.5455MHZ-6-K2Z-T3 24.5455MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-24.5455MHZ-7-B1U-T3 24.5455MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-24.5455MHZ-7-B2U-T3 24.5455MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-24.5455MHZ-7-D1X-T3 24.5455MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-24.5455MHZ-7-D2X-T3 24.5455MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-24.5455MHZ-7-J1Z-T3 24.5455MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-24.5455MHZ-7-J2Z-T3 24.5455MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-24.5455MHZ-7-K1Z-T3 24.5455MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-24.5455MHZ-7-K2Z-T3 24.5455MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-24.5455MHZ-8-B1U-T3 24.5455MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-24.5455MHZ-8-B2U-T3 24.5455MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-24.5455MHZ-8-D1X-T3 24.5455MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-24.5455MHZ-8-D2X-T3 24.5455MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-24.5455MHZ-8-J1Z-T3 24.5455MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-24.5455MHZ-8-J2Z-T3 24.5455MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-24.5455MHZ-8-K1Z-T3 24.5455MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-24.5455MHZ-8-K2Z-T3 24.5455MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-24.5535MHZ-4-D1X-T3 24.5535MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-24.5535MHZ-4-D2X-T3 24.5535MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-24.5535MHZ-6-B1U-T3 24.5535MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-24.5535MHZ-6-B2U-T3 24.5535MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-24.5535MHZ-6-D1X-T3 24.5535MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-24.5535MHZ-6-D2X-T3 24.5535MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-24.5535MHZ-6-J1Z-T3 24.5535MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-24.5535MHZ-6-J2Z-T3 24.5535MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-24.5535MHZ-6-K1Z-T3 24.5535MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-24.5535MHZ-6-K2Z-T3 24.5535MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-24.5535MHZ-7-B1U-T3 24.5535MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-24.5535MHZ-7-B2U-T3 24.5535MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-24.5535MHZ-7-D1X-T3 24.5535MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-24.5535MHZ-7-D2X-T3 24.5535MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-24.5535MHZ-7-J1Z-T3 24.5535MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-24.5535MHZ-7-J2Z-T3 24.5535MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-24.5535MHZ-7-K1Z-T3 24.5535MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-24.5535MHZ-7-K2Z-T3 24.5535MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-24.5535MHZ-8-B1U-T3 24.5535MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-24.5535MHZ-8-B2U-T3 24.5535MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-24.5535MHZ-8-D1X-T3 24.5535MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-24.5535MHZ-8-D2X-T3 24.5535MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-24.5535MHZ-8-J1Z-T3 24.5535MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-24.5535MHZ-8-J2Z-T3 24.5535MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-24.5535MHZ-8-K1Z-T3 24.5535MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-24.5535MHZ-8-K2Z-T3 24.5535MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-24.5727MHZ-4-D1X-T3 24.5727MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-24.5727MHZ-4-D2X-T3 24.5727MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-24.5727MHZ-6-B1U-T3 24.5727MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-24.5727MHZ-6-B2U-T3 24.5727MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-24.5727MHZ-6-D1X-T3 24.5727MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-24.5727MHZ-6-D2X-T3 24.5727MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-24.5727MHZ-6-J1Z-T3 24.5727MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-24.5727MHZ-6-J2Z-T3 24.5727MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-24.5727MHZ-6-K1Z-T3 24.5727MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-24.5727MHZ-6-K2Z-T3 24.5727MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-24.5727MHZ-7-B1U-T3 24.5727MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-24.5727MHZ-7-B2U-T3 24.5727MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-24.5727MHZ-7-D1X-T3 24.5727MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-24.5727MHZ-7-D2X-T3 24.5727MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-24.5727MHZ-7-J1Z-T3 24.5727MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-24.5727MHZ-7-J2Z-T3 24.5727MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-24.5727MHZ-7-K1Z-T3 24.5727MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-24.5727MHZ-7-K2Z-T3 24.5727MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-24.5727MHZ-8-B1U-T3 24.5727MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-24.5727MHZ-8-B2U-T3 24.5727MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-24.5727MHZ-8-D1X-T3 24.5727MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-24.5727MHZ-8-D2X-T3 24.5727MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-24.5727MHZ-8-J1Z-T3 24.5727MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-24.5727MHZ-8-J2Z-T3 24.5727MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-24.5727MHZ-8-K1Z-T3 24.5727MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-24.5727MHZ-8-K2Z-T3 24.5727MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-24.5760MHZ-4-D1X-T3 24.576MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-24.5760MHZ-4-D2X-T3 24.576MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-24.5760MHZ-6-B1U-T3 24.576MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-24.5760MHZ-6-B2U-T3 24.576MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-24.5760MHZ-6-D1X-T3 24.576MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-24.5760MHZ-6-D2X-T3 24.576MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-24.5760MHZ-6-J1Z-T3 24.576MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-24.5760MHZ-6-J2Z-T3 24.576MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-24.5760MHZ-6-K1Z-T3 24.576MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-24.5760MHZ-6-K2Z-T3 24.576MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-24.5760MHZ-7-B1U-T3 24.576MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-24.5760MHZ-7-B2U-T3 24.576MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-24.5760MHZ-7-D1X-T3 24.576MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-24.5760MHZ-7-D2X-T3 24.576MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-24.5760MHZ-7-J1Z-T3 24.576MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-24.5760MHZ-7-J2Z-T3 24.576MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-24.5760MHZ-7-K1Z-T3 24.576MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-24.5760MHZ-7-K2Z-T3 24.576MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-24.5760MHZ-8-B1U-T3 24.576MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-24.5760MHZ-8-B2U-T3 24.576MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-24.5760MHZ-8-D2X-T3 24.576MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-24.5760MHZ-8-J1Z-T3 24.576MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-24.5760MHZ-8-J2Z-T3 24.576MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-24.5760MHZ-8-K1Z-T3 24.576MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-24.5760MHZ-8-K2Z-T3 24.576MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-24.9231MHZ-4-D1X-T3 24.9231MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-24.9231MHZ-4-D2X-T3 24.9231MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-24.9231MHZ-6-B1U-T3 24.9231MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-24.9231MHZ-6-B2U-T3 24.9231MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-24.9231MHZ-6-D1X-T3 24.9231MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-24.9231MHZ-6-D2X-T3 24.9231MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-24.9231MHZ-6-J1Z-T3 24.9231MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-24.9231MHZ-6-J2Z-T3 24.9231MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-24.9231MHZ-6-K1Z-T3 24.9231MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-24.9231MHZ-6-K2Z-T3 24.9231MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-24.9231MHZ-7-B1U-T3 24.9231MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-24.9231MHZ-7-B2U-T3 24.9231MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-24.9231MHZ-7-D1X-T3 24.9231MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-24.9231MHZ-7-D2X-T3 24.9231MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-24.9231MHZ-7-J1Z-T3 24.9231MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-24.9231MHZ-7-J2Z-T3 24.9231MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-24.9231MHZ-7-K1Z-T3 24.9231MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-24.9231MHZ-7-K2Z-T3 24.9231MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-24.9231MHZ-8-B1U-T3 24.9231MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-24.9231MHZ-8-B2U-T3 24.9231MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-24.9231MHZ-8-D1X-T3 24.9231MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-24.9231MHZ-8-D2X-T3 24.9231MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-24.9231MHZ-8-J1Z-T3 24.9231MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-24.9231MHZ-8-J2Z-T3 24.9231MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-24.9231MHZ-8-K1Z-T3 24.9231MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-24.9231MHZ-8-K2Z-T3 24.9231MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-25.0000MHZ-4-D2X-T3 25MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-25.0000MHZ-6-B2U-T3 25MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-25.0000MHZ-6-D2X-T3 25MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-25.0000MHZ-6-J1Z-T3 25MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-25.0000MHZ-6-J2Z-T3 25MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-25.0000MHZ-6-K1Z-T3 25MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-25.0000MHZ-7-B2U-T3 25MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-25.0000MHZ-7-D2X-T3 25MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-25.0000MHZ-7-J1Z-T3 25MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-25.0000MHZ-7-J2Z-T3 25MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-25.0000MHZ-7-K1Z-T3 25MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-25.0000MHZ-7-K2Z-T3 25MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-25.0000MHZ-8-B2U-T3 25MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-25.0000MHZ-8-D2X-T3 25MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-25.0000MHZ-8-J1Z-T3 25MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-25.0000MHZ-8-J2Z-T3 25MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-25.0000MHZ-8-K1Z-T3 25MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-25.0000MHZ-8-K2Z-T3 25MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-26.0000MHZ-4-B2U-T3 26MHz ±10ppm 4pF -20°C ~ 70°C
      ABM12W-26.0000MHZ-4-D1X-T3 26MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-26.0000MHZ-4-D2X-T3 26MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-26.0000MHZ-4-J1Z-T3 26MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-26.0000MHZ-4-J2Z-T3 26MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-26.0000MHZ-6-B2U-T3 26MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-26.0000MHZ-6-D2X-T3 26MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-26.0000MHZ-6-J1Z-T3 26MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-26.0000MHZ-6-J2Z-T3 26MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-26.0000MHZ-6-K1Z-T3 26MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-26.0000MHZ-6-K2Z-T3 26MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-26.0000MHZ-7-B2U-T3 26MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-26.0000MHZ-7-D2X-T3 26MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-26.0000MHZ-7-J1Z-T3 26MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-26.0000MHZ-7-J2Z-T3 26MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-26.0000MHZ-7-K1Z-T3 26MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-26.0000MHZ-7-K2Z-T3 26MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-26.0000MHZ-8-B2U-T3 26MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-26.0000MHZ-8-D2X-T3 26MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-26.0000MHZ-8-J1Z-T3 26MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-26.0000MHZ-8-J2Z-T3 26MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-26.0000MHZ-8-K1Z-T3 26MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-26.0000MHZ-8-K2Z-T3 26MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-26.0410MHZ-4-B1U-T3 26.041MHz ±10ppm 4pF -20°C ~ 70°C
      ABM12W-26.0410MHZ-4-B2U-T3 26.041MHz ±10ppm 4pF -20°C ~ 70°C
      ABM12W-26.0410MHZ-4-D1X-T3 26.041MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-26.0410MHZ-4-D2X-T3 26.041MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-26.0410MHZ-4-J1Z-T3 26.041MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-26.0410MHZ-4-J2Z-T3 26.041MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-26.0410MHZ-6-B1U-T3 26.041MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-26.0410MHZ-6-B2U-T3 26.041MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-26.0410MHZ-6-D1X-T3 26.041MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-26.0410MHZ-6-D2X-T3 26.041MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-26.0410MHZ-6-J1Z-T3 26.041MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-26.0410MHZ-6-J2Z-T3 26.041MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-26.0410MHZ-6-K1Z-T3 26.041MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-26.0410MHZ-6-K2Z-T3 26.041MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-26.0410MHZ-7-B1U-T3 26.041MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-26.0410MHZ-7-B2U-T3 26.041MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-26.0410MHZ-7-D1X-T3 26.041MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-26.0410MHZ-7-D2X-T3 26.041MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-26.0410MHZ-7-J1Z-T3 26.041MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-26.0410MHZ-7-J2Z-T3 26.041MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-26.0410MHZ-7-K1Z-T3 26.041MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-26.0410MHZ-7-K2Z-T3 26.041MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-26.0410MHZ-8-B1U-T3 26.041MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-26.0410MHZ-8-B2U-T3 26.041MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-26.0410MHZ-8-D1X-T3 26.041MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-26.0410MHZ-8-D2X-T3 26.041MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-26.0410MHZ-8-J1Z-T3 26.041MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-26.0410MHZ-8-J2Z-T3 26.041MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-26.0410MHZ-8-K1Z-T3 26.041MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-26.0410MHZ-8-K2Z-T3 26.041MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-27.0000MHZ-4-B2U-T3 27MHz ±10ppm 4pF -20°C ~ 70°C
      ABM12W-27.0000MHZ-4-D1X-T3 27MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-27.0000MHZ-4-D2X-T3 27MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-27.0000MHZ-4-J1Z-T3 27MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-27.0000MHZ-4-J2Z-T3 27MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-27.0000MHZ-6-B2U-T3 27MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-27.0000MHZ-6-D2X-T3 27MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-27.0000MHZ-6-J1Z-T3 27MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-27.0000MHZ-6-J2Z-T3 27MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-27.0000MHZ-6-K1Z-T3 27MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-27.0000MHZ-6-K2Z-T3 27MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-27.0000MHZ-7-B2U-T3 27MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-27.0000MHZ-7-D2X-T3 27MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-27.0000MHZ-7-J1Z-T3 27MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-27.0000MHZ-7-J2Z-T3 27MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-27.0000MHZ-7-K1Z-T3 27MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-27.0000MHZ-7-K2Z-T3 27MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-27.0000MHZ-8-B2U-T3 27MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-27.0000MHZ-8-D2X-T3 27MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-27.0000MHZ-8-J1Z-T3 27MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-27.0000MHZ-8-J2Z-T3 27MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-27.0000MHZ-8-K1Z-T3 27MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-27.0000MHZ-8-K2Z-T3 27MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-27.1200MHZ-4-B1U-T3 27.12MHz ±10ppm 4pF -20°C ~ 70°C
      ABM12W-27.1200MHZ-4-B2U-T3 27.12MHz ±10ppm 4pF -20°C ~ 70°C
      ABM12W-27.1200MHZ-4-D2X-T3 27.12MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-27.1200MHZ-4-J1Z-T3 27.12MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-27.1200MHZ-4-J2Z-T3 27.12MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-27.1200MHZ-6-B2U-T3 27.12MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-27.1200MHZ-6-D2X-T3 27.12MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-27.1200MHZ-6-J1Z-T3 27.12MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-27.1200MHZ-6-J2Z-T3 27.12MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-27.1200MHZ-6-K1Z-T3 27.12MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-27.1200MHZ-6-K2Z-T3 27.12MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-27.1200MHZ-7-B2U-T3 27.12MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-27.1200MHZ-7-D2X-T3 27.12MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-27.1200MHZ-7-J1Z-T3 27.12MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-27.1200MHZ-7-J2Z-T3 27.12MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-27.1200MHZ-7-K1Z-T3 27.12MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-27.1200MHZ-7-K2Z-T3 27.12MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-27.1200MHZ-8-B2U-T3 27.12MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-27.1200MHZ-8-D2X-T3 27.12MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-27.1200MHZ-8-J1Z-T3 27.12MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-27.1200MHZ-8-J2Z-T3 27.12MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-27.1200MHZ-8-K2Z-T3 27.12MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-28.2240MHZ-4-B1U-T3 28.224MHz ±10ppm 4pF -20°C ~ 70°C
      ABM12W-28.2240MHZ-4-B2U-T3 28.224MHz ±10ppm 4pF -20°C ~ 70°C
      ABM12W-28.2240MHZ-4-D1X-T3 28.224MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-28.2240MHZ-4-D2X-T3 28.224MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-28.2240MHZ-4-J1Z-T3 28.224MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-28.2240MHZ-4-J2Z-T3 28.224MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-28.3220MHZ-4-B1U-T3 28.322MHz ±10ppm 4pF -20°C ~ 70°C
      ABM12W-28.3220MHZ-4-B2U-T3 28.322MHz ±10ppm 4pF -20°C ~ 70°C
      ABM12W-28.3220MHZ-4-D1X-T3 28.322MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-28.3220MHZ-4-D2X-T3 28.322MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-28.3220MHZ-4-J1Z-T3 28.322MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-28.3220MHZ-4-J2Z-T3 28.322MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-28.6364MHZ-4-B1U-T3 28.6364MHz ±10ppm 4pF -20°C ~ 70°C
      ABM12W-28.6364MHZ-4-B2U-T3 28.6364MHz ±10ppm 4pF -20°C ~ 70°C
      ABM12W-28.6364MHZ-4-D1X-T3 28.6364MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-28.6364MHZ-4-D2X-T3 28.6364MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-28.6364MHZ-4-J1Z-T3 28.6364MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-28.6364MHZ-4-J2Z-T3 28.6364MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-29.4912MHZ-4-B1U-T3 29.4912MHz ±10ppm 4pF -20°C ~ 70°C
      ABM12W-29.4912MHZ-4-B2U-T3 29.4912MHz ±10ppm 4pF -20°C ~ 70°C
      ABM12W-29.4912MHZ-4-D1X-T3 29.4912MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-29.4912MHZ-4-D2X-T3 29.4912MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-29.4912MHZ-4-J1Z-T3 29.4912MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-29.4912MHZ-4-J2Z-T3 29.4912MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-30.0000MHZ-4-D1X-T3 30MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-30.0000MHZ-4-J1Z-T3 30MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-30.0000MHZ-4-J2Z-T3 30MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-30.0000MHZ-6-B2U-T3 30MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-30.0000MHZ-6-D2X-T3 30MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-30.0000MHZ-6-J1Z-T3 30MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-30.0000MHZ-6-J2Z-T3 30MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-30.0000MHZ-6-K1Z-T3 30MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-30.0000MHZ-6-K2Z-T3 30MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-30.0000MHZ-7-B2U-T3 30MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-30.0000MHZ-7-D2X-T3 30MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-30.0000MHZ-7-J1Z-T3 30MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-30.0000MHZ-7-J2Z-T3 30MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-30.0000MHZ-7-K1Z-T3 30MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-30.0000MHZ-7-K2Z-T3 30MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-30.0000MHZ-8-B2U-T3 30MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-30.0000MHZ-8-D2X-T3 30MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-30.0000MHZ-8-J1Z-T3 30MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-30.0000MHZ-8-J2Z-T3 30MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-30.0000MHZ-8-K1Z-T3 30MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-30.0000MHZ-8-K2Z-T3 30MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-30.3200MHZ-4-D1X-T3 30.32MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-30.3200MHZ-4-D2X-T3 30.32MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-30.3200MHZ-4-J1Z-T3 30.32MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-30.3200MHZ-4-J2Z-T3 30.32MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-30.4000MHZ-4-D1X-T3 30.4MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-30.4000MHZ-4-D2X-T3 30.4MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-30.4000MHZ-4-J1Z-T3 30.4MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-30.4000MHZ-4-J2Z-T3 30.4MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-30.7200MHZ-4-D1X-T3 30.72MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-30.7200MHZ-4-D2X-T3 30.72MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-30.7200MHZ-4-J1Z-T3 30.72MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-30.7200MHZ-4-J2Z-T3 30.72MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-31.2500MHZ-4-D1X-T3 31.25MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-31.2500MHZ-4-D2X-T3 31.25MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-31.2500MHZ-4-J1Z-T3 31.25MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-31.2500MHZ-4-J2Z-T3 31.25MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-32.0000MHZ-4-J1Z-T3 32MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-32.0000MHZ-4-J2Z-T3 32MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-32.0000MHZ-6-B2U-T3 32MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-32.0000MHZ-6-J1Z-T3 32MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-32.0000MHZ-6-J2Z-T3 32MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-32.0000MHZ-6-K1Z-T3 32MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-32.0000MHZ-6-K2Z-T3 32MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-32.0000MHZ-7-B2U-T3 32MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-32.0000MHZ-7-D2X-T3 32MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-32.0000MHZ-7-J1Z-T3 32MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-32.0000MHZ-7-J2Z-T3 32MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-32.0000MHZ-7-K1Z-T3 32MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-32.0000MHZ-7-K2Z-T3 32MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-32.0000MHZ-8-J2Z-T3 32MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-33.0000MHZ-4-D1X-T3 33MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-33.0000MHZ-4-D2X-T3 33MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-33.0000MHZ-4-J1Z-T3 33MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-33.0000MHZ-4-J2Z-T3 33MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-33.0000MHZ-6-B1U-T3 33MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-33.0000MHZ-6-B2U-T3 33MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-33.0000MHZ-6-D1X-T3 33MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-33.0000MHZ-6-D2X-T3 33MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-33.0000MHZ-6-J1Z-T3 33MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-33.0000MHZ-6-J2Z-T3 33MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-33.0000MHZ-6-K1Z-T3 33MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-33.0000MHZ-6-K2Z-T3 33MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-33.0000MHZ-7-B1U-T3 33MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-33.0000MHZ-7-B2U-T3 33MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-33.0000MHZ-7-D1X-T3 33MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-33.0000MHZ-7-D2X-T3 33MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-33.0000MHZ-7-J1Z-T3 33MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-33.0000MHZ-7-J2Z-T3 33MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-33.0000MHZ-7-K1Z-T3 33MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-33.0000MHZ-7-K2Z-T3 33MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-33.0000MHZ-8-B1U-T3 33MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-33.0000MHZ-8-B2U-T3 33MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-33.0000MHZ-8-D1X-T3 33MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-33.0000MHZ-8-D2X-T3 33MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-33.0000MHZ-8-J1Z-T3 33MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-33.0000MHZ-8-J2Z-T3 33MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-33.0000MHZ-8-K1Z-T3 33MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-33.0000MHZ-8-K2Z-T3 33MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-33.3300MHZ-4-D1X-T3 33.33MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-33.3300MHZ-4-D2X-T3 33.33MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-33.3300MHZ-4-J1Z-T3 33.33MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-33.3300MHZ-4-J2Z-T3 33.33MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-33.3300MHZ-6-B1U-T3 33.33MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-33.3300MHZ-6-B2U-T3 33.33MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-33.3300MHZ-6-D1X-T3 33.33MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-33.3300MHZ-6-D2X-T3 33.33MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-33.3300MHZ-6-J1Z-T3 33.33MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-33.3300MHZ-6-J2Z-T3 33.33MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-33.3300MHZ-6-K1Z-T3 33.33MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-33.3300MHZ-6-K2Z-T3 33.33MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-33.3300MHZ-7-B1U-T3 33.33MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-33.3300MHZ-7-B2U-T3 33.33MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-33.3300MHZ-7-D1X-T3 33.33MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-33.3300MHZ-7-D2X-T3 33.33MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-33.3300MHZ-7-J1Z-T3 33.33MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-33.3300MHZ-7-J2Z-T3 33.33MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-33.3300MHZ-7-K1Z-T3 33.33MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-33.3300MHZ-7-K2Z-T3 33.33MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-33.3300MHZ-8-B1U-T3 33.33MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-33.3300MHZ-8-B2U-T3 33.33MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-33.3300MHZ-8-D2X-T3 33.33MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-33.3300MHZ-8-J1Z-T3 33.33MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-33.3300MHZ-8-J2Z-T3 33.33MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-33.3300MHZ-8-K1Z-T3 33.33MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-33.3300MHZ-8-K2Z-T3 33.33MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-33.3330MHZ-4-D1X-T3 33.333MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-33.3330MHZ-4-D2X-T3 33.333MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-33.3330MHZ-4-J1Z-T3 33.333MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-33.3330MHZ-4-J2Z-T3 33.333MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-33.3330MHZ-6-B1U-T3 33.333MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-33.3330MHZ-6-B2U-T3 33.333MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-33.3330MHZ-6-D1X-T3 33.333MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-33.3330MHZ-6-D2X-T3 33.333MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-33.3330MHZ-6-J1Z-T3 33.333MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-33.3330MHZ-6-J2Z-T3 33.333MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-33.3330MHZ-6-K1Z-T3 33.333MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-33.3330MHZ-6-K2Z-T3 33.333MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-33.3330MHZ-7-B1U-T3 33.333MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-33.3330MHZ-7-B2U-T3 33.333MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-33.3330MHZ-7-D1X-T3 33.333MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-33.3330MHZ-7-D2X-T3 33.333MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-33.3330MHZ-7-J1Z-T3 33.333MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-33.3330MHZ-7-J2Z-T3 33.333MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-33.3330MHZ-7-K1Z-T3 33.333MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-33.3330MHZ-7-K2Z-T3 33.333MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-33.3330MHZ-8-B1U-T3 33.333MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-33.3330MHZ-8-B2U-T3 33.333MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-33.3330MHZ-8-D1X-T3 33.333MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-33.3330MHZ-8-D2X-T3 33.333MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-33.3330MHZ-8-J1Z-T3 33.333MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-33.3330MHZ-8-J2Z-T3 33.333MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-33.3330MHZ-8-K1Z-T3 33.333MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-33.3330MHZ-8-K2Z-T3 33.333MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-33.3333MHZ-6-B1U-T3 33.3333MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-33.3333MHZ-6-B2U-T3 33.3333MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-33.3333MHZ-6-D1X-T3 33.3333MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-33.3333MHZ-6-D2X-T3 33.3333MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-33.3333MHZ-6-J1Z-T3 33.3333MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-33.3333MHZ-6-J2Z-T3 33.3333MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-33.3333MHZ-6-K1Z-T3 33.3333MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-33.3333MHZ-6-K2Z-T3 33.3333MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-33.3333MHZ-7-B2U-T3 33.3333MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-33.3333MHZ-7-D1X-T3 33.3333MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-33.3333MHZ-7-D2X-T3 33.3333MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-33.3333MHZ-7-J1Z-T3 33.3333MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-33.3333MHZ-7-J2Z-T3 33.3333MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-33.3333MHZ-7-K1Z-T3 33.3333MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-33.3333MHZ-7-K2Z-T3 33.3333MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-33.3333MHZ-8-B1U-T3 33.3333MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-33.3333MHZ-8-B2U-T3 33.3333MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-33.3333MHZ-8-D1X-T3 33.3333MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-33.3333MHZ-8-D2X-T3 33.3333MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-33.3333MHZ-8-J1Z-T3 33.3333MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-33.3333MHZ-8-J2Z-T3 33.3333MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-33.3333MHZ-8-K1Z-T3 33.3333MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-33.3333MHZ-8-K2Z-T3 33.3333MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-36.0000MHZ-6-B2U-T3 36MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-36.0000MHZ-6-D2X-T3 36MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-36.0000MHZ-6-J1Z-T3 36MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-36.0000MHZ-6-J2Z-T3 36MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-36.0000MHZ-6-K1Z-T3 36MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-36.0000MHZ-6-K2Z-T3 36MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-36.0000MHZ-7-B2U-T3 36MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-36.0000MHZ-7-D2X-T3 36MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-36.0000MHZ-7-J1Z-T3 36MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-36.0000MHZ-7-J2Z-T3 36MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-36.0000MHZ-7-K1Z-T3 36MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-36.0000MHZ-7-K2Z-T3 36MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-36.0000MHZ-8-B2U-T3 36MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-36.0000MHZ-8-D2X-T3 36MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-36.0000MHZ-8-J1Z-T3 36MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-36.0000MHZ-8-J2Z-T3 36MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-36.0000MHZ-8-K1Z-T3 36MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-36.0000MHZ-8-K2Z-T3 36MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-37.0000MHZ-4-D1X-T3 37MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-37.0000MHZ-4-D2X-T3 37MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-37.0000MHZ-4-J1Z-T3 37MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-37.0000MHZ-4-J2Z-T3 37MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-37.0000MHZ-6-B1U-T3 37MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-37.0000MHZ-6-B2U-T3 37MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-37.0000MHZ-6-D1X-T3 37MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-37.0000MHZ-6-D2X-T3 37MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-37.0000MHZ-6-J1Z-T3 37MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-37.0000MHZ-6-J2Z-T3 37MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-37.0000MHZ-6-K1Z-T3 37MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-37.0000MHZ-6-K2Z-T3 37MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-37.0000MHZ-7-B1U-T3 37MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-37.0000MHZ-7-B2U-T3 37MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-37.0000MHZ-7-D1X-T3 37MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-37.0000MHZ-7-D2X-T3 37MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-37.0000MHZ-7-J1Z-T3 37MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-37.0000MHZ-7-J2Z-T3 37MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-37.0000MHZ-7-K1Z-T3 37MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-37.0000MHZ-7-K2Z-T3 37MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-37.0000MHZ-8-B1U-T3 37MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-37.0000MHZ-8-B2U-T3 37MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-37.0000MHZ-8-D1X-T3 37MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-37.0000MHZ-8-D2X-T3 37MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-37.0000MHZ-8-J1Z-T3 37MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-37.0000MHZ-8-J2Z-T3 37MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-37.0000MHZ-8-K1Z-T3 37MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-37.0000MHZ-8-K2Z-T3 37MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-37.0500MHZ-4-D1X-T3 37.05MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-37.0500MHZ-4-D2X-T3 37.05MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-37.0500MHZ-4-J1Z-T3 37.05MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-37.0500MHZ-4-J2Z-T3 37.05MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-37.0500MHZ-6-B1U-T3 37.05MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-37.0500MHZ-6-B2U-T3 37.05MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-37.0500MHZ-6-D1X-T3 37.05MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-37.0500MHZ-6-D2X-T3 37.05MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-37.0500MHZ-6-J1Z-T3 37.05MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-37.0500MHZ-6-J2Z-T3 37.05MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-37.0500MHZ-6-K1Z-T3 37.05MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-37.0500MHZ-6-K2Z-T3 37.05MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-37.0500MHZ-7-B1U-T3 37.05MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-37.0500MHZ-7-B2U-T3 37.05MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-37.0500MHZ-7-D1X-T3 37.05MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-37.0500MHZ-7-D2X-T3 37.05MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-37.0500MHZ-7-J1Z-T3 37.05MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-37.0500MHZ-7-J2Z-T3 37.05MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-37.0500MHZ-7-K1Z-T3 37.05MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-37.0500MHZ-7-K2Z-T3 37.05MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-37.0500MHZ-8-B1U-T3 37.05MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-37.0500MHZ-8-B2U-T3 37.05MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-37.0500MHZ-8-D1X-T3 37.05MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-37.0500MHZ-8-D2X-T3 37.05MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-37.0500MHZ-8-J1Z-T3 37.05MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-37.0500MHZ-8-J2Z-T3 37.05MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-37.0500MHZ-8-K1Z-T3 37.05MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-37.0500MHZ-8-K2Z-T3 37.05MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-37.4000MHZ-4-D2X-T3 37.4MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-37.4000MHZ-4-J1Z-T3 37.4MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-37.4000MHZ-4-J2Z-T3 37.4MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-37.4000MHZ-6-B1U-T3 37.4MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-37.4000MHZ-6-B2U-T3 37.4MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-37.4000MHZ-6-D1X-T3 37.4MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-37.4000MHZ-6-D2X-T3 37.4MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-37.4000MHZ-6-J1Z-T3 37.4MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-37.4000MHZ-6-J2Z-T3 37.4MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-37.4000MHZ-6-K1Z-T3 37.4MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-37.4000MHZ-6-K2Z-T3 37.4MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-37.4000MHZ-7-B1U-T3 37.4MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-37.4000MHZ-7-B2U-T3 37.4MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-37.4000MHZ-7-D2X-T3 37.4MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-37.4000MHZ-7-J1Z-T3 37.4MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-37.4000MHZ-7-J2Z-T3 37.4MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-37.4000MHZ-7-K1Z-T3 37.4MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-37.4000MHZ-7-K2Z-T3 37.4MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-37.4000MHZ-8-B1U-T3 37.4MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-37.4000MHZ-8-B2U-T3 37.4MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-37.4000MHZ-8-D2X-T3 37.4MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-37.4000MHZ-8-J1Z-T3 37.4MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-37.4000MHZ-8-J2Z-T3 37.4MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-37.4000MHZ-8-K1Z-T3 37.4MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-37.4000MHZ-8-K2Z-T3 37.4MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-38.0000MHZ-4-D1X-T3 38MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-38.0000MHZ-4-D2X-T3 38MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-38.0000MHZ-4-J1Z-T3 38MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-38.0000MHZ-4-J2Z-T3 38MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-38.0000MHZ-6-B1U-T3 38MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-38.0000MHZ-6-B2U-T3 38MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-38.0000MHZ-6-D1X-T3 38MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-38.0000MHZ-6-D2X-T3 38MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-38.0000MHZ-6-J1Z-T3 38MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-38.0000MHZ-6-J2Z-T3 38MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-38.0000MHZ-6-K1Z-T3 38MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-38.0000MHZ-6-K2Z-T3 38MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-38.0000MHZ-7-B1U-T3 38MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-38.0000MHZ-7-B2U-T3 38MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-38.0000MHZ-7-D1X-T3 38MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-38.0000MHZ-7-D2X-T3 38MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-38.0000MHZ-7-J1Z-T3 38MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-38.0000MHZ-7-J2Z-T3 38MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-38.0000MHZ-7-K1Z-T3 38MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-38.0000MHZ-7-K2Z-T3 38MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-38.0000MHZ-8-B1U-T3 38MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-38.0000MHZ-8-B2U-T3 38MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-38.0000MHZ-8-D1X-T3 38MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-38.0000MHZ-8-J1Z-T3 38MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-38.0000MHZ-8-J2Z-T3 38MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-38.0000MHZ-8-K1Z-T3 38MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-38.0000MHZ-8-K2Z-T3 38MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-38.4000MHZ-4-D2X-T3 38.4MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-38.4000MHZ-4-J1Z-T3 38.4MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-38.4000MHZ-4-J2Z-T3 38.4MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-38.4000MHZ-6-B1U-T3 38.4MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-38.4000MHZ-6-B2U-T3 38.4MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-38.4000MHZ-6-D1X-T3 38.4MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-38.4000MHZ-6-D2X-T3 38.4MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-38.4000MHZ-6-J1Z-T3 38.4MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-38.4000MHZ-6-J2Z-T3 38.4MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-38.4000MHZ-6-K1Z-T3 38.4MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-38.4000MHZ-6-K2Z-T3 38.4MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-38.4000MHZ-7-B1U-T3 38.4MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-38.4000MHZ-7-B2U-T3 38.4MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-38.4000MHZ-7-D1X-T3 38.4MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-38.4000MHZ-7-D2X-T3 38.4MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-38.4000MHZ-7-J1Z-T3 38.4MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-38.4000MHZ-7-J2Z-T3 38.4MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-38.4000MHZ-7-K1Z-T3 38.4MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-38.4000MHZ-7-K2Z-T3 38.4MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-38.4000MHZ-8-B1U-T3 38.4MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-38.4000MHZ-8-B2U-T3 38.4MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-38.4000MHZ-8-J1Z-T3 38.4MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-38.4000MHZ-8-J2Z-T3 38.4MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-38.4000MHZ-8-K1Z-T3 38.4MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-38.4000MHZ-8-K2Z-T3 38.4MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-38.8800MHZ-4-D1X-T3 38.88MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-38.8800MHZ-4-D2X-T3 38.88MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-38.8800MHZ-4-J1Z-T3 38.88MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-38.8800MHZ-4-J2Z-T3 38.88MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-38.8800MHZ-6-B1U-T3 38.88MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-38.8800MHZ-6-B2U-T3 38.88MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-38.8800MHZ-6-D1X-T3 38.88MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-38.8800MHZ-6-D2X-T3 38.88MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-38.8800MHZ-6-J1Z-T3 38.88MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-38.8800MHZ-6-J2Z-T3 38.88MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-38.8800MHZ-6-K1Z-T3 38.88MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-38.8800MHZ-6-K2Z-T3 38.88MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-38.8800MHZ-7-B1U-T3 38.88MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-38.8800MHZ-7-B2U-T3 38.88MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-38.8800MHZ-7-D1X-T3 38.88MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-38.8800MHZ-7-D2X-T3 38.88MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-38.8800MHZ-7-J1Z-T3 38.88MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-38.8800MHZ-7-J2Z-T3 38.88MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-38.8800MHZ-7-K1Z-T3 38.88MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-38.8800MHZ-7-K2Z-T3 38.88MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-38.8800MHZ-8-B1U-T3 38.88MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-38.8800MHZ-8-B2U-T3 38.88MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-38.8800MHZ-8-D1X-T3 38.88MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-38.8800MHZ-8-D2X-T3 38.88MHz ±20ppm 8pF -40°C ~ 85°C
      ABM12W-38.8800MHZ-8-J1Z-T3 38.88MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-38.8800MHZ-8-J2Z-T3 38.88MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-38.8800MHZ-8-K1Z-T3 38.88MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-38.8800MHZ-8-K2Z-T3 38.88MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-39.0000MHZ-4-D1X-T3 39MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-39.0000MHZ-4-D2X-T3 39MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-39.0000MHZ-4-J1Z-T3 39MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-39.0000MHZ-4-J2Z-T3 39MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-40.0000MHZ-4-D1X-T3 40MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-40.0000MHZ-4-D2X-T3 40MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-40.0000MHZ-4-J1Z-T3 40MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-40.0000MHZ-4-J2Z-T3 40MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-40.0000MHZ-6-B2U-T3 40MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-40.0000MHZ-6-D2X-T3 40MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-40.0000MHZ-6-J1Z-T3 40MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-40.0000MHZ-6-J2Z-T3 40MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-40.0000MHZ-6-K1Z-T3 40MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-40.0000MHZ-6-K2Z-T3 40MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-40.0000MHZ-7-B2U-T3 40MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-40.0000MHZ-7-D2X-T3 40MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-40.0000MHZ-7-J1Z-T3 40MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-40.0000MHZ-7-J2Z-T3 40MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-40.0000MHZ-7-K1Z-T3 40MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-40.0000MHZ-7-K2Z-T3 40MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-40.0000MHZ-8-J1Z-T3 40MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-40.0000MHZ-8-J2Z-T3 40MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-40.0000MHZ-8-K1Z-T3 40MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-40.0000MHZ-8-K2Z-T3 40MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-40.6100MHZ-4-D1X-T3 40.61MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-40.6100MHZ-4-D2X-T3 40.61MHz ±20ppm 4pF -40°C ~ 85°C
      ABM12W-40.6100MHZ-4-J1Z-T3 40.61MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-40.6100MHZ-4-J2Z-T3 40.61MHz ±50ppm 4pF -40°C ~ 105°C
      ABM12W-48.0000MHZ-6-B2U-T3 48MHz ±10ppm 6pF -20°C ~ 70°C
      ABM12W-48.0000MHZ-6-D2X-T3 48MHz ±20ppm 6pF -40°C ~ 85°C
      ABM12W-48.0000MHZ-6-J1Z-T3 48MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-48.0000MHZ-6-J2Z-T3 48MHz ±50ppm 6pF -40°C ~ 105°C
      ABM12W-48.0000MHZ-6-K1Z-T3 48MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-48.0000MHZ-6-K2Z-T3 48MHz ±50ppm 6pF -40°C ~ 125°C
      ABM12W-48.0000MHZ-7-B2U-T3 48MHz ±10ppm 7pF -20°C ~ 70°C
      ABM12W-48.0000MHZ-7-D2X-T3 48MHz ±20ppm 7pF -40°C ~ 85°C
      ABM12W-48.0000MHZ-7-J1Z-T3 48MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-48.0000MHZ-7-J2Z-T3 48MHz ±50ppm 7pF -40°C ~ 105°C
      ABM12W-48.0000MHZ-7-K1Z-T3 48MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-48.0000MHZ-7-K2Z-T3 48MHz ±50ppm 7pF -40°C ~ 125°C
      ABM12W-48.0000MHZ-8-B2U-T3 48MHz ±10ppm 8pF -20°C ~ 70°C
      ABM12W-48.0000MHZ-8-J1Z-T3 48MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-48.0000MHZ-8-J2Z-T3 48MHz ±50ppm 8pF -40°C ~ 105°C
      ABM12W-48.0000MHZ-8-K1Z-T3 48MHz ±50ppm 8pF -40°C ~ 125°C
      ABM12W-48.0000MHZ-8-K2Z-T3 48MHz ±50ppm 8pF -40°C ~ 125°C


      爆款产品

      undefined

      ABM3B-8.000MHZ-D4Y-T

      详细信息

      undefined

      ABM2-12.000MHZ-D4Y-T

      详细信息

      undefined

      ABMM-6.000MHZ-D2-T

      详细信息

      undefined

      ABS06-127-32.768KHZ-T

      详细信息

      undefined

      ASAK-32.768KHZ-LR-T

      详细信息

      undefined

      ASFL1-8.000MHZ-EC-T

      详细信息

      undefined

      ABS07-32.768KHZ-T

      详细信息

      undefined

      ASV-50.000MHZ-LC-T

      详细信息

      精选产品

      ABRACON CRYSTAL

      undefined

      ABLS-12.000MHZ-B4-T



      了解详情

      ABRACON CRYSTAL

      undefined

      ABMM2-25.000MHZ-D1-T



      了解详情

      ABRACON CRYSTAL

      undefined

      ABM3-12.000MHZ-D2Y-T


      了解详情

      ABRACON CRYSTAL

      undefined

      ABLS-3.579545MHZ-D-3-Y-T


      了解详情

      新闻推荐




      我们的优势

      undefined

      十三年专注 品牌优势现货渠道商。

      免费提供技术支持服务

      提供专业的技术支持服务和免费规格书,减少不必要的盲目选型。

      了解详情

      频点齐全交期短

      加科电子常规频点长期有现货,交期短,满足您产品的需求。

      使用入门

      高效准确无误

      当某品牌缺货同时,我们能够高效准确无误的找到其他品牌与之替代的型号。

      了解详情

      专业主攻晶振

      专业主攻晶振,销售品牌均为市场成熟品牌,且有知名度被国内企业所认可。

      关于 Abracon LLC


      Abracon是全球领先的无源和机电定时,同步,电源,连接和射频解决方案制造商,Abracon拥有广泛的石英晶振,晶体和MEMS振荡器,实时时钟,功率感应器,物联网天线等产品组合,晶振作为一种高精度,高可靠性的时钟源,被广泛应用于各种电子设备中,具备稳定性和准确性,能够为电子设备提供更为精准的计时信号,晶振的稳定性和准确性对于许多电子设备的运行至关重要。ABRACON晶振现货商品的产品介绍和图片,请浏览我们的网站www.smdxtal.com/。


      联系人.jpg联系人：黄河15602443498

      座机.jpg座机：0755-33533774

      邮箱邮箱：jiakedz@163.com

      QQQQ：3080074590

      定位地址：深圳市宝安区13区宝民一路白金大厦13F

      网址：//www.michaelogg.com

      40MHz晶振 1612 7PF 10PPM ABM12W-40.0000MHZ-8-D1X-T3 ABRACON晶振
      *表示必填 采购：40MHz晶振,1612,7PF,10PPM,ABM12W-40.0000MHZ-8-D1X-T3,ABRACON晶振
      *联系人： 请填写您的真实姓名
      公司名称： 请填写您的公司名称
      联系电话：
      *手机号码： 请填写您的联系电话
      电子邮件：
      联系地址：
      *采购意向描述：
      请填写采购的产品数量和产品描述,方便我们进行统一备货。
      验证码： 验证码
      跟此产品相关的产品

      共有-条评论【我要评论】

      正在加载...
      查看全部评论
      我要评论:
      内 容：
      （内容最多500个汉字,1000个字符）
      验证码： 看不清？！
      加科电子产品中心

      晶振分类

      台系晶振

      晶振用途

      晶振规格书

      联系加科电子Contact

      咨询热线：0755-33533774

      传真：0755-33533774

      QQ：3080074590

      邮箱：jiakedz@163.com

      地址：深圳市宝安区宝民一路123号3号楼13F

      晶振用途 批发中心 技术与服务 成功案例 客户见证 加科资讯 网站地图
      版权所有
      公司地址：深圳市宝安区宝民一路123号3号楼13F
      联系电话：0755-33533774
      传 真： 0755-33533774 电子邮箱：jiakedz@163.com
      技术支持：牛商网络
      备案号： 粤ICP备14062413号

      百度统计 CNZZ

      Baidu
      map
