12MHz晶振,ABM3-12.000MHz-D2Y-T,ABRACON晶振

产品分类：晶振规格书

订购热线： 0755-33533774

跟此产品相关的产品

: 12MHz晶振 5032晶振 ABM3-12.000MHZ-D2Y-T 18PF 20PPM ABRACON晶振

产品详情

料号	频率(MHZ)	工作温度	负载电容	精度
ABM3-15.000MHz-B4Y-T	15MHz	20°C+70°C	18PF	±30PPM
ABM3-22.1184MHz-D2Y-T	22.1184MHz	40°C+85°C	18PF	±20PPM
ABM3-13.000MHz-B4Y-T	13MHz	20°C+70°C	18PF	±30PPM
ABM3-24.576MHz-B4Y-T	24.576MHz	20°C+70°C	18PF	±30PPM
ABM3-50.000MHz-D2Y-F-T	50MHz	40°C+85°C	18PF	±20PPM
ABM3-13.52313MHz-10-B4Y-T	13.52313MHz	20°C+70°C	10PF	±30PPM
ABM3-11.0592MHz-D2Y-T	11.0592MHz	40°C+85°C	18PF	±20PPM
ABM3-8.000MHz-B4Y-T	8MHz	20°C+70°C	18PF	±30PPM
ABM3-24.576MHz-D2Y-T	24.576MHz	40°C+85°C	18PF	±20PPM
ABM3-16.000MHz-D2Y-T	16MHz	40°C+85°C	18PF	±20PPM
ABM3-12.000MHz-D2Y-T	12MHz	40°C+85°C	18PF	±20PPM
ABM3-24.576MHz-B2-T	24.576MHz	20°C+70°C	18PF	±20PPM
ABM3-33.000MHz-B2-T	33MHz	20°C+70°C	18PF	±20PPM
ABM3-33.000MHz-D2Y-T	33MHz	40°C+85°C	18PF	±20PPM
ABM3-40.000MHz-B2-T	40MHz	20°C+70°C	18PF	±20PPM
ABM3-14.31818MHz-B2-T	14.31818MHz	20°C+70°C	18PF	±20PPM
ABM3-10.000MHz-B4Y-T	10MHz	20°C+70°C	18PF	±30PPM
ABM3-13.560MHz-B4Y-T	13.56MHz	20°C+70°C	18PF	±30PPM
ABM3-27.000MHz-B4Y-T	27MHz	20°C+70°C	18PF	±30PPM
ABM3-33.000MHz-B4Y-T	33MHz	20°C+70°C	18PF	±30PPM
ABM3-48.000MHz-B4Y-T	48MHz	20°C+70°C	18PF	±30PPM
ABM3-29.4912MHz-B4Y-T	29.4912MHz	20°C+70°C	18PF	±30PPM
ABM3-19.6608MHz-B4Y-T	19.6608MHz	20°C+70°C	18PF	±30PPM
ABM3-24.000MHz-B4Y-T	24MHz	20°C+70°C	18PF	±30PPM
ABM3-48.000MHz-B2-T	48MHz	20°C+70°C	18PF	±20PPM
ABM3-14.31818MHz-B4Y-T	14.31818MHz	20°C+70°C	18PF	±30PPM
ABM3-19.6608MHz-D2Y-T	19.6608MHz	40°C+85°C	18PF	±20PPM
ABM3-9.8304MHz-D2Y-T	9.8304MHz	40°C+85°C	18PF	±20PPM
ABM3-30.000MHz-B4Y-T	30MHz	20°C+70°C	18PF	±30PPM
ABM3-32.000MHz-B4Y-T	32MHz	20°C+70°C	18PF	±30PPM
ABM3-20.000MHz-B4Y-T	20MHz	20°C+70°C	18PF	±30PPM
ABM3-11.0592MHz-B4Y-T	11.0592MHz	20°C+70°C	18PF	±30PPM
ABM3-22.1184MHz-B4Y-T	22.1184MHz	20°C+70°C	18PF	±30PPM
ABM3-40.000MHz-B4Y-T	40MHz	20°C+70°C	18PF	±30PPM
ABM3-18.432MHz-B4Y-T	18.432MHz	20°C+70°C	18PF	±30PPM
ABM3-12.000MHz-B4Y-T	12MHz	20°C+70°C	18PF	±30PPM
ABM3-25.000MHz-B4Y-T	25MHz	20°C+70°C	18PF	±30PPM
ABM3-30.000MHz-B2-T	30MHz	20°C+70°C	18PF	±20PPM
ABM3-26.000MHz-B4Y-T	26MHz	20°C+70°C	18PF	±30PPM
ABM3-14.7456MHz-B4Y-T	14.7456MHz	20°C+70°C	18PF	±30PPM
ABM3-16.000MHz-B4Y-T	16MHz	20°C+70°C	18PF	±30PPM
ABM3-11.2896MHz-D2Y-T	11.2896MHz	40°C+85°C	18PF	±20PPM
ABM3-29.4912MHz-B2-T	29.4912MHz	20°C+70°C	18PF	±20PPM
ABM3-27.000MHz-B2-T	27MHz	20°C+70°C	18PF	±20PPM
ABM3-28.6363MHz-B2-T	28.6363MHz	20°C+70°C	18PF	±20PPM
ABM3-14.7456MHz-D2Y-T	14.7456MHz	40°C+85°C	18PF	±20PPM
ABM3-32.000MHz-D2Y-T	32MHz	40°C+85°C	18PF	±20PPM
ABM3-18.432MHz-B2-T	18.432MHz	20°C+70°C	18PF	±20PPM
ABM3-18.432MHz-D2Y-T	18.432MHz	40°C+85°C	18PF	±20PPM
ABM3-10.0000MHz-D2Y-T	10MHz	40°C+85°C	18PF	±20PPM
ABM3-8.192MHz-B4Y-T	8.192MHz	20°C+70°C	18PF	±30PPM
ABM3-12.288MHz-B4Y-T	12.288MHz	20°C+70°C	18PF	±30PPM
ABM3-27.000MHz-D2Y-T	27MHz	40°C+85°C	18PF	±20PPM
ABM3-20.000MHz-D2Y-T	20MHz	40°C+85°C	18PF	±20PPM
ABM3-25.000MHz-B2-T	25MHz	20°C+70°C	18PF	±20PPM
ABM3-13.560MHz-B2-T	13.56MHz	20°C+70°C	18PF	±20PPM
ABM3-30.000MHz-D2Y-T	30MHz	40°C+85°C	18PF	±20PPM
ABM3-16.384MHz-B4Y-T	16.384MHz	20°C+70°C	18PF	±30PPM
ABM3-9.8304MHz-B4Y-T	9.8304MHz	20°C+70°C	18PF	±30PPM
ABM3-40.000MHz-D2Y-F-T	40MHz	40°C+85°C	18PF	±20PPM
ABM3-25.000MHz-D2Y-T	25MHz	40°C+85°C	18PF	±20PPM
ABM3-12.288MHz-D2Y-T	12.288MHz	40°C+85°C	18PF	±20PPM
ABM3-24.000MHz-D2Y-T	24MHz	40°C+85°C	18PF	±20PPM
ABM3-8.000MHz-D2Y-T	8MHz	40°C+85°C	18PF	±20PPM
ABM3-12.000MHz-B2-T	12MHz	20°C+70°C	18PF	±20PPM
ABM3-20.000MHz-B2-T	20MHz	20°C+70°C	18PF	±20PPM
ABM3-24.000MHz-B2-T	24MHz	20°C+70°C	18PF	±20PPM
ABM3-16.000MHz-B2-T	16MHz	20°C+70°C	18PF	±20PPM
ABM3-14.31818MHz-D2Y-T	14.31818MHz	40°C+85°C	18PF	±20PPM
