| 型号 | 外部尺寸（mm） | 工作温度（℃） | 频率范围 | PDF下载 |
| CSX-750F | 7.0x5.0x1.6mm | -20°C+70°C -40°C+85°C | 1MHz~39.9MHz | PDF下载 |
| CSX-532T | 5.0×3.2×1.5mm | -30°C+75°C | 12.8MHz~26MHz | PDF下载 |
| CSX-325T | 3.2x2.5x1.0mm | -30°C+75°C | 13MHz~52MHz | PDF下载 |
| CSX-252F | 2.5x2.0x0.8mm | -20°C+70°C -40°C+85°C | 32.768KHz 2MHz～39.999MHz | PDF下载 |
| CSX-252T | 2.5x2.0x1.0mm | -30°C+75°C | 19.2MHz 26MHz 38.4MHz | PDF下载 |
| HCM49 | 11.4x4.7x4.3mm | -40°C+85°C | 12MHz~54MHz | PDF下载 |
| HC-49 / U-S | 11.5x4.66x3.5mm | -20°C+70°C | 3.5MHz~50MHz | PDF下载 |
| CM309S | 12.4x4.4x3.6mm | -40°C+85°C | 3.5MHz~34MHz | PDF下载 |
| CS20 | 11.6x5.5x2.2mm | -40°C+85°C | 3.5MHz~30MHz | PDF下载 |
| CS10 | 6.0x3.5x1.0mm | -40°C+85°C | 12MHz~50MHz | PDF下载 |
| CS325S | 3.2x2.5x0.6mm | -40°C+85°C | 12MHz~54MHz | PDF下载 |
| CM1610H | 1.6×1.0×0.5mm | -40°C+85°C | 32.768KHz | PDF下载 |
| CM2012H | 2.0x1.2x0.6mm | -40°C+85°C | 32.768KHz | PDF下载 |
| CM250C | 8.0x3.8x2.55mm | -40°C+85°C | 30KHz~100KHz | PDF下载 |
| CM200C | 8.0x3.8x2.55mm | -40°C+85°C | 32.768KHz | PDF下载 |
| CM519 | 4.9x1.8x1.0mm | -40°C+85°C | 32.768KHz | PDF下载 |
| CM415 | 4.1x1.5x0.9mm | -40°C+85°C | 32.768KHz | PDF下载 |
| CM130 | 7.0x1.5x1.4mm | -40°C+85°C | 32.768KHz | PDF下载 |
| CMJ206T | 8.6 x2.7x2.4mm | -40°C+85°C | 32.768KHz | PDF下载 |
| CMR200T | 2x6mm | -40°C+85°C | 32.768KHz | PDF下载 |
