一般来说,当采购员和工程师购买晶振并在振荡器电路中使用时,需要在安装之前提供模拟设置。这些包括负载电容、振荡余量和温度变化。爱普生的晶体振荡器已经提供了这些设置,所以它们的输出信号可以直接控制TTL和CMOS IC,这大大缩短了工程师的设计过程,并有助于标准化所使用的组件。爱普生振荡器时钟振荡器还具有VCXO功能和尝试状态功能。VCXO功能通过外部控制电压控制输出频率,并且输出通过使输出端具有控制信号而使通电时保持输出端处于高阻抗状态。

下面加科晶体电子为大家介绍一款由EPSON公司超高性价比的可编程晶振SG-8018系列,它的温度范围扩展到105°C,具有标准的SPXO精度（±50ppm,其中包括老化）,并且还可以编写输出波形的上升和下降沿时间。此款可编程晶振具有高效率、紧凑、高精度、短批量生产等优点而广泛应用于汽车多媒体、汽车电子、遥控钥匙锁、汽车行驶安全等汽车应用领域。在时间上,可用现场振荡器编程工具SG编写器等应用（发动机控制单元、安全气囊、电子稳定程序控制系统）等。SG-8018系列可编程晶振可以在任意频率定做,灵活易用,在许多特殊的设计需要的产品青睐,如需要快速原型应用,替代交互式周期性现场产品解决方案,非标准频率,简化BOM等。最常用的场合,SG-8018可编程系列晶振适用于空间敏感无线应用,为无线通信设备提供精确的时钟信号,提高使用寿命和耐久性,缩短产品开发周期。

SG-8018可编程系列晶振型号分为四种SG-8018CA、SG-8018CB、SG-8018CE、SG-8018CG。频率调节精度可达1 ppm。与同类元件相比,功耗和频率稳定性显著提高。电源电压为1.62V~3.63V,支持CMOS电平输出,有利于设备的集成设计。输出启用和待机模式由OE和ST引脚切换。当输出频率为20MHz时,空载电流损失低至2.7Ma。在待机模式下,静态电流仅为0.3MUA,这使得更容易实现低功耗设计。此款可编程晶振还具有快速启动特性。晶体振荡器的启动时间为3ms,默认模式和快速模式的上升/下降时间仅为3.0nS。此外,通过选择SG编写器II软件实现了可编程功能,增加了系统设计的灵活性。下面给大家SG-8018可编程晶振系列四款不同封装规格型号的订货型号。

SG-8101CA

订货型号	频率	尺寸	型号	电压	工作温度范围	精度
X1G0051910028	125.000000MHz	7.00 x 5.00 x 1.40 mm	SG-8101CA	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0051910013	100.000000MHz	7.00 x 5.00 x 1.40 mm	SG-8101CA	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0051910030	98.304000 MHz	7.00 x 5.00 x 1.40 mm	SG-8101CA	1.620 to 3.630 V	-40 to +105 °C	+/-20 ppm
X1G0051910014	80.000000 MHz	7.00 x 5.00 x 1.40 mm	SG-8101CA	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0051910018	73.333700 MHz	7.00 x 5.00 x 1.40 mm	SG-8101CA	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0051910023	69.120000 MHz	7.00 x 5.00 x 1.40 mm	SG-8101CA	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0051910025	66.666000 MHz	7.00 x 5.00 x 1.40 mm	SG-8101CA	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0051910019	60.000300 MHz	7.00 x 5.00 x 1.40 mm	SG-8101CA	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0051910012	60.000000 MHz	7.00 x 5.00 x 1.40 mm	SG-8101CA	1.620 to 3.630 V	-40 to +105 °C	+/-50 ppm
X1G0051910029	50.000000 MHz	7.00 x 5.00 x 1.40 mm	SG-8101CA	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0051910015	48.000000 MHz	7.00 x 5.00 x 1.40 mm	SG-8101CA	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0051910033	40.000000 MHz	7.00 x 5.00 x 1.40 mm	SG-8101CA	1.620 to 3.630 V	-40 to +105 °C	+/-20 ppm
X1G0051910011	32.507937 MHz	7.00 x 5.00 x 1.40 mm	SG-8101CA	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0051910016	27.500000 MHz	7.00 x 5.00 x 1.40 mm	SG-8101CA	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0051910022	25.000000 MHz	7.00 x 5.00 x 1.40 mm	SG-8101CA	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0051910027	25.000000 MHz	7.00 x 5.00 x 1.40 mm	SG-8101CA	1.620 to 3.630 V	-40 to +105 °C	+/-20 ppm
X1G0051910032	22.660000 MHz	7.00 x 5.00 x 1.40 mm	SG-8101CA	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0051910017	22.500000 MHz	7.00 x 5.00 x 1.40 mm	SG-8101CA	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0051910020	22.000000 MHz	7.00 x 5.00 x 1.40 mm	SG-8101CA	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0051910021	18.000000 MHz	7.00 x 5.00 x 1.40 mm	SG-8101CA	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0051910026	13.516800 MHz	7.00 x 5.00 x 1.40 mm	SG-8101CA	1.620 to 3.630 V	-40 to +105 °C	+/-50 ppm
X1G0051910031	10.000000 MHz	7.00 x 5.00 x 1.40 mm	SG-8101CA	1.620 to 3.630 V	-40 to +105 °C	+/-50 ppm
X1G0051910024	5.560000 MHz	7.00 x 5.00 x 1.40 mm	SG-8101CA	1.620 to 3.630 V	-40 to +105 °C	+/-50 ppm

SG-8101CB

订货型号	频率	尺寸	型号	电压	工作温度	精度
X1G0052010020	153.600000 MHz	5.00 x 3.20 x 1.20 mm	SG-8101CB	1.620 to 3.630 V	-40 to +105 °C	+/-50 ppm
X1G0052010014	148.500000 MHz	5.00 x 3.20 x 1.20 mm	SG-8101CB	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0052010013	148.351648 MHz	5.00 x 3.20 x 1.20 mm	SG-8101CB	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0052010011	133.000000 MHz	5.00 x 3.20 x 1.20 mm	SG-8101CB	1.620 to 3.630 V	-40 to +105 °C	+/-50 ppm
X1G0052010012	100.000000 MHz	5.00 x 3.20 x 1.20 mm	SG-8101CB	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0052010016	50.000000 MHz	5.00 x 3.20 x 1.20 mm	SG-8101CB	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0052010019	48.000000 MHz	5.00 x 3.20 x 1.20 mm	SG-8101CB	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0052010018	28.636400 MHz	5.00 x 3.20 x 1.20 mm	SG-8101CB	1.620 to 3.630 V	-40 to +105 °C	+/-20 ppm
X1G0052010015	27.000000 MHz	5.00 x 3.20 x 1.20 mm	SG-8101CB	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0052010017	24.545400 MHz	5.00 x 3.20 x 1.20 mm	SG-8101CB	1.620 to 3.630 V	-40 to +105 °C	+/-20 ppm

SG-8101CE

订货型号	频率	尺寸	型号	电压	工作温度	精度
X1G0052110024	156.250000 MHz	3.20 x 2.50 x 1.20 mm	SG-8101CE	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0052110027	148.500000 MHz	3.20 x 2.50 x 1.20 mm	SG-8101CE	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0052110043	133.000000 MHz	3.20 x 2.50 x 1.20 mm	SG-8101CE	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0052110025	125.000000 MHz	3.20 x 2.50 x 1.20 mm	SG-8101CE	1.620 to 3.630 V	-40 to +105 °C	+/-20 ppm
X1G0052110044	114.285000 MHz	3.20 x 2.50 x 1.20 mm	SG-8101CE	1.620 to 3.630 V	-40 to +105 °C	+/-20 ppm
X1G0052110029	100.000000 MHz	3.20 x 2.50 x 1.20 mm	SG-8101CE	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0052110020	100.000000 MHz	3.20 x 2.50 x 1.20 mm	SG-8101CE	1.620 to 3.630 V	-40 to +105 °C	+/-20 ppm
X1G0052110039	98.304000 MHz	3.20 x 2.50 x 1.20 mm	SG-8101CE	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0052110035	88.888800 MHz	3.20 x 2.50 x 1.20 mm	SG-8101CE	1.620 to 3.630 V	-40 to +105 °C	+/-50 ppm
X1G0052110021	80.000000 MHz	3.20 x 2.50 x 1.20 mm	SG-8101CE	1.620 to 3.630 V	-40 to +105 °C	+/-20 ppm
X1G0052110014	72.000000 MHz	3.20 x 2.50 x 1.20 mm	SG-8101CE	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0052110037	70.047536 MHz	3.20 x 2.50 x 1.20 mm	SG-8101CE	1.620 to 3.630 V	-40 to +105 °C	+/-20 ppm
X1G0052110028	70.000000 MHz	3.20 x 2.50 x 1.20 mm	SG-8101CE	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0052110038	60.787000 MHz	3.20 x 2.50 x 1.20 mm	SG-8101CE	1.620 to 3.630 V	-40 to +105 °C	+/-20 ppm
X1G0052110045	50.000000 MHz	3.20 x 2.50 x 1.20 mm	SG-8101CE	1.620 to 3.630 V	-40 to +105 °C	+/-20 ppm
X1G0052110015	50.000000 MHz	3.20 x 2.50 x 1.20 mm	SG-8101CE	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0052110022	48.000000 MHz	3.20 x 2.50 x 1.20 mm	SG-8101CE	1.620 to 3.630 V	-40 to +105 °C	+/-20 ppm
X1G0052110013	46.080000 MHz	3.20 x 2.50 x 1.20 mm	SG-8101CE	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0052110012	41.580000 MHz	3.20 x 2.50 x 1.20 mm	SG-8101CE	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0052110016	40.000000 MHz	3.20 x 2.50 x 1.20 mm	SG-8101CE	1.620 to 3.630 V	-40 to +105 °C	+/-20 ppm
X1G0052110041	32.768000 MHz	3.20 x 2.50 x 1.20 mm	SG-8101CE	1.620 to 3.630 V	-40 to +105 °C	+/-20 ppm
X1G0052110030	32.673000 MHz	3.20 x 2.50 x 1.20 mm	SG-8101CE	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0052110031	32.000000 MHz	3.20 x 2.50 x 1.20 mm	SG-8101CE	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0052110040	30.000000 MHz	3.20 x 2.50 x 1.20 mm	SG-8101CE	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0052110033	27.000000 MHz	3.20 x 2.50 x 1.20 mm	SG-8101CE	1.620 to 3.630 V	-40 to +105 °C	+/-20 ppm
X1G0052110023	25.000500 MHz	3.20 x 2.50 x 1.20 mm	SG-8101CE	1.620 to 3.630 V	-40 to +105 °C	+/-20 ppm
X1G0052110018	25.000000 MHz	3.20 x 2.50 x 1.20 mm	SG-8101CE	1.620 to 3.630 V	-40 to +105 °C	+/-50 ppm
X1G0052110011	25.000000 MHz	3.20 x 2.50 x 1.20 mm	SG-8101CE	1.620 to 3.630 V	-40 to +105 °C	+/-20 ppm
X1G0052110036	22.660000 MHz	3.20 x 2.50 x 1.20 mm	SG-8101CE	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0052110026	20.000000 MHz	3.20 x 2.50 x 1.20 mm	SG-8101CE	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0052110017	12.500000 MHz	3.20 x 2.50 x 1.20 mm	SG-8101CE	1.620 to 3.630 V	-40 to +105 °C	+/-50 ppm
X1G0052110019	10.000000 MHz	3.20 x 2.50 x 1.20 mm	SG-8101CE	1.620 to 3.630 V	-40 to +105 °C	+/-50 ppm
X1G0052110046	8.704000 MHz	3.20 x 2.50 x 1.20 mm	SG-8101CE	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0052110034	3.686400 MHz	3.20 x 2.50 x 1.20 mm	SG-8101CE	1.620 to 3.630 V	-40 to +105 °C	+/-20 ppm
X1G0052110032	2.000000 MHz	3.20 x 2.50 x 1.20 mm	SG-8101CE	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0052110042	1.544000 MHz	3.20 x 2.50 x 1.20 mm	SG-8101CE	1.620 to 3.630 V	-40 to +105 °C	+/-20 ppm

SG-8101CG

订货型号	频率	尺寸	型号	电压	工作温度	精度
X1G0051810015	100.000000 MHz	2.50 x 2.00 x 0.80 mm	SG-8101CG	1.620 to 3.630 V	-40 to +105 °C	+/-20 ppm
X1G0051810036	96.000000 MHz	2.50 x 2.00 x 0.80 mm	SG-8101CG	1.620 to 3.630 V	-40 to +105 °C	+/-20 ppm
X1G0051810020	80.000000 MHz	2.50 x 2.00 x 0.80 mm	SG-8101CG	1.620 to 3.630 V	-40 to +105 °C	+/-20 ppm
X1G0051810044	74.176000 MHz	2.50 x 2.00 x 0.80 mm	SG-8101CG	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0051810026	68.000000 MHz	2.50 x 2.00 x 0.80 mm	SG-8101CG	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0051810013	66.666660 MHz	2.50 x 2.00 x 0.80 mm	SG-8101CG	1.620 to 3.630 V	-40 to +105 °C	+/-20 ppm
X1G0051810021	58.982400 MHz	2.50 x 2.00 x 0.80 mm	SG-8101CG	1.620 to 3.630 V	-40 to +105 °C	+/-50 ppm
X1G0051810024	50.000000 MHz	2.50 x 2.00 x 0.80 mm	SG-8101CG	1.620 to 3.630 V	-40 to +105 °C	+/-20 ppm
X1G0051810037	49.152000 MHz	2.50 x 2.00 x 0.80 mm	SG-8101CG	1.620 to 3.630 V	-40 to +105 °C	+/-20 ppm
X1G0051810042	48.000000 MHz	2.50 x 2.00 x 0.80 mm	SG-8101CG	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0051810046	48.000000 MHz	2.50 x 2.00 x 0.80 mm	SG-8101CG	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0051810011	48.000000 MHz	2.50 x 2.00 x 0.80 mm	SG-8101CG	1.620 to 3.630 V	-40 to +105 °C	+/-20 ppm
X1G0051810045	43.000000 MHz	2.50 x 2.00 x 0.80 mm	SG-8101CG	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0051810023	40.000000 MHz	2.50 x 2.00 x 0.80 mm	SG-8101CG	1.620 to 3.630 V	-40 to +105 °C	+/-20 ppm
X1G0051810030	39.321600 MHz	2.50 x 2.00 x 0.80 mm	SG-8101CG	1.620 to 3.630 V	-40 to +105 °C	+/-50 ppm
X1G0051810048	35.000000 MHz	2.50 x 2.00 x 0.80 mm	SG-8101CG	1.620 to 3.630 V	-40 to +105 °C	+/-50 ppm
X1G0051810039	33.333000 MHz	2.50 x 2.00 x 0.80 mm	SG-8101CG	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0051810031	31.250000 MHz	2.50 x 2.00 x 0.80 mm	SG-8101CG	1.620 to 3.630 V	-40 to +105 °C	+/-20 ppm
X1G0051810018	25.000000 MHz	2.50 x 2.00 x 0.80 mm	SG-8101CG	1.620 to 3.630 V	-40 to +105 °C	+/-20 ppm
X1G0051810017	25.000000 MHz	2.50 x 2.00 x 0.80 mm	SG-8101CG	1.620 to 3.630 V	-40 to +105 °C	+/-20 ppm
X1G0051810040	25.000000 MHz	2.50 x 2.00 x 0.80 mm	SG-8101CG	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0051810022	25.000000 MHz	2.50 x 2.00 x 0.80 mm	SG-8101CG	1.620 to 3.630 V	-40 to +105 °C	+/-20 ppm
X1G0051810029	25.000000 MHz	2.50 x 2.00 x 0.80 mm	SG-8101CG	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0051810014	24.000000 MHz	2.50 x 2.00 x 0.80 mm	SG-8101CG	1.620 to 3.630 V	-40 to +105 °C	+/-20 ppm
X1G0051810027	24.000000 MHz	2.50 x 2.00 x 0.80 mm	SG-8101CG	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0051810041	21.000000 MHz	2.50 x 2.00 x 0.80 mm	SG-8101CG	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0051810038	20.000000 MHz	2.50 x 2.00 x 0.80 mm	SG-8101CG	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0051810028	16.000000 MHz	2.50 x 2.00 x 0.80 mm	SG-8101CG	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0051810025	16.000000 MHz	2.50 x 2.00 x 0.80 mm	SG-8101CG	1.620 to 3.630 V	-40 to +105 °C	+/-20 ppm
X1G0051810016	16.000000 MHz	2.50 x 2.00 x 0.80 mm	SG-8101CG	1.620 to 3.630 V	-40 to +105 °C	+/-20 ppm
X1G0051810032	16.000000 MHz	2.50 x 2.00 x 0.80 mm	SG-8101CG	1.620 to 3.630 V	-40 to +85 °C	+/-15 ppm
X1G0051810033	12.000000 MHz	2.50 x 2.00 x 0.80 mm	SG-8101CG	1.620 to 3.630 V	-40 to +105 °C	+/-20 ppm
X1G0051810034	8.192000 MHz	2.50 x 2.00 x 0.80 mm	SG-8101CG	1.620 to 3.630 V	-40 to +105 °C	+/-20 ppm
X1G0051810035	5.000000 MHz	2.50 x 2.00 x 0.80 mm	SG-8101CG	1.620 to 3.630 V	-40 to +105 °C	+/-20 ppm
X1G0051810047	2.048000 MHz	2.50 x 2.00 x 0.80 mm	SG-8101CG	1.620 to 3.630 V	-40 to +105 °C	+/-20 ppm
X1G0051810043	1.544000 MHz	2.50 x 2.00 x 0.80 mm	SG-8101CG	1.620 to 3.630 V	-40 to +105 °C	+/-20 ppm
X1G0051810019	1.000000 MHz	2.50 x 2.00 x 0.80 mm	SG-8101CG	1.620 to 3.630 V	-40 to +105 °C	+/-20 ppm
