台湾晶技TXC晶振是全球最大的晶振产品制造商,实现了从KHz到MHz的全覆盖。稳定的供应、良好的一致性、更稳定的性能、5年以上无频率偏移、振动停止等。TXC有源晶振采用先进工艺,将性能稳定的水晶材质和半导体行业使用的微机电加工技术完美集合,确保产品体积小、性能高、稳定性高、一致性高、成本低。在同类高品质有源晶振中,价格跟有优势。
TXC晶振通用类有源晶振SPXO明星产品推荐8W,7X,7C,7W封装,晶振频率覆盖1MHz-125MHz,电源电压1.6V~3.6V,工作温度范围-40℃~+85℃。其中8W频率覆盖4-75MHz,性能稳定,可替代多种品牌。在工业产品,仪器仪表和小型可穿戴设备应用非常之多。
01
8W系列2520有源晶振料号
| 料号 | 频率 | 电压 | 精度 | 工作温度 |
| 8W75072001 | 75 MHz | 1.8V | ±25ppm | 0°C ~ 70°C |
| 8W26070002 | 26 MHz | 3.3V | ±50ppm | -10°C ~ 70°C |
| 8W12000013 | 12 MHz | 1.8V | ±20ppm | -20°C ~ 70°C |
| 8W13070002 | 13 MHz | 3.3V | ±50ppm | -10°C ~ 70°C |
| 8W50000010 | 50 MHz | 3.3V | ±50ppm | -40°C ~ 85°C |
| 8W26000011 | 26 MHz | 1.8V | - | -20°C ~ 70°C |
| 8W50000002 | 50 MHz | 3.3V | ±50ppm | -10°C ~ 70°C |
| 8W26000019 | 26 MHz | 3.3V | ±20ppm | -40°C ~ 85°C |
| 8W26000011 | 26 MHz | 1.8V | - | -20°C ~ 70°C |
| 8W26000004 | 26 MHz | 1.8V | - | -20°C ~ 85°C |
| 8W12220001 | 12.288 MHz | 1.8V | ±50ppm | -40°C ~ 85°C |
| 8W40020001 | 40 MHz | 3.3V | ±50ppm | -10°C ~ 70°C |
| 8W62570002 | 62.5 MHz | 1.8V | ±70ppm | 0°C ~ 70°C |
| 8W12000013 | 12 MHz | 1.8V | ±20ppm | -20°C ~ 70°C |
| 8W13070002 | 13 MHz | 3.3V | ±50ppm | -10°C ~ 70°C |
| 8W25077003 | 25 MHz | 1.8V | ±30ppm | -40°C ~ 85°C |
| 8W48070002 | 48 MHz | 3.3V | ±50ppm | -10°C ~ 70°C |
02
7C系列5032有源晶振料号
| 料号 | 频率 | 电压 | 精度 | 工作温度 |
| 7C24000012 | 24 MHz | 3.3V | ±30ppm | -10°C ~ 70°C |
| 7C40000290 | 40 MHz | 1.8V | - | - |
| 7C40000192 | 40 MHz | 2.8V | - | - |
| 7C08000001 | 8 MHz | 3.3V | ±50ppm | -10°C ~ 70°C |
| 7C24070002 | 24 MHz | 1.8V | ±25ppm | -10°C ~ 70°C |
| 7C24500002 | 24.576 MHz | 3.3V | ±20ppm | -20°C ~ 70°C |
| 7CA2502001 | 125 MHz | 3.3V | ±50ppm | -40°C ~ 85°C |
| 7C24000006 | 24 MHz | 1.8V | ±20ppm | -20°C ~ 70°C |
| 7C24020001 | 24 MHz | 3.3V | ±30ppm | -20°C ~ 70°C |
| 7C24070007 | 24 MHz | 3.3V | ±30ppm | -10°C ~ 70°C |
| 7C50000001 | 50 MHz | 3.3V | ±25ppm | -10°C ~ 70°C |
| 7C20000003 | 20 MHz | 3.3V | ±30ppm | -40°C ~ 85°C |
| 7C25000011 | 25 MHz | 3.3V | ±50ppm | -40°C ~ 85°C |
| 7C35000001 | 35 MHz | 3.3V | ±50ppm | -10°C ~ 70°C |
| 7C33370001 | 33.333 MHz | 3.3V | ±50ppm | -40°C ~ 85°C |
| 7C42100001 | 42.15 MHz | 3.3V | ±50ppm | -40°C ~ 85°C |
| 7C60000027 | 60 MHz | 3.3V | ±50ppm | 0°C ~ 70°C |
| 7CA0002001 | 100 MHz | 3.3V | ±50ppm | -10°C ~ 70°C |
| 7C40000281 | 40 MHz | 1.8V | ±20ppm | -20°C ~ 75°C |
| 7CA2570003 | 125 MHz | 3.3V | ±50ppm | -10°C ~ 70°C |
| 7C25000123 | 25 MHz | 3.3V | ±20ppm | -10°C ~ 70°C |
| 7C25002005 | 25 MHz | 1.8V | ±50ppm | -40°C ~ 85°C |
| 7C27000014 | 27 MHz | 3.3V | ±50ppm | -10°C ~ 70°C |
| 7C25077004 | 25 MHz | 3.3V | ±50ppm | -40°C ~ 85°C |
| 7C75000600 | 75 MHz | 1.8V | ±30ppm | -40°C ~ 85°C |
| 7C40000067 | 40 MHz | 3.3V | ±50ppm | -40°C ~ 85°C |
| 7C75077001 | 75 MHz | 1.8V | ±50ppm | -40°C ~ 85°C |
| 7C20000003 | 20 MHz | 3.3V | ±30ppm | -40°C ~ 85°C |
| 7C25000011 | 25 MHz | 3.3V | ±50ppm | -40°C ~ 85°C |
| 7C35000001 | 35 MHz | 3.3V | ±50ppm | -10°C ~ 70°C |
| 7C33370001 | 33.333 MHz | 3.3V | ±50ppm | -40°C ~ 85°C |
| 7C42100001 | 42.15 MHz | 3.3V | ±50ppm | -40°C ~ 85°C |
| 7C60000027 | 60 MHz | 3.3V | ±50ppm | 0°C ~ 70°C |
| 7CA0002001 | 100 MHz | 3.3V | ±50ppm | -10°C ~ 70°C |
| 7C25000016 | 25 MHz | 3.3V | ±50ppm | -10°C ~ 70°C |
| 7C25070001 | 25 MHz | 3.3V | ±50ppm | -40°C ~ 85°C |
| 7C66600009 | 66.66 MHz | 3.3V | ±50ppm | -40°C ~ 85°C |
| 7C06123001 | 6.144 MHz | 3.3V | ±50ppm | -40°C ~ 85°C |
| 7C50077004 | 50 MHz | 1.8V | ±50ppm | -40°C ~ 85°C |
| 7C80000014 | 80 MHz | 2.8V | ±25ppm | -10°C ~ 75°C |
| 7C40000076 | 40 MHz | 3.3V | ±20ppm | -10°C ~ 70°C |
| 7C25077004 | 25 MHz | 3.3V | ±50ppm | -40°C ~ 85°C |
| 7C75000600 | 75 MHz | 1.8V | ±30ppm | -40°C ~ 85°C |
| 7C26000083 | 26 MHz | 1.8V | ±20ppm | -30°C ~ 85°C |
| 7C50077002 | 50 MHz | 3.3V | ±25ppm | -40°C ~ 85°C |
| AC40000003 | 40 MHz | 2.8V | ±10ppm | -40°C ~ 85°C |
| AC42170001 | 42.15 MHz | 2.8V | ±50ppm | -40°C ~ 85°C |
| 7C24000006 | 24 MHz | 1.8V | ±20ppm | -20°C ~ 70°C |
| 7C24020001 | 24 MHz | 3.3V | ±30ppm | -20°C ~ 70°C |
| 7C24070007 | 24 MHz | 3.3V | ±30ppm | -10°C ~ 70°C |
| 7C50000001 | 50 MHz | 3.3V | ±25ppm | -10°C ~ 70°C |
| 7C16000017 | 16 MHz | 3.3V | ±30ppm | -20°C ~ 70°C |
| 7C50000015 | 50 MHz | 3.3V | ±50ppm | -10°C ~ 70°C |
| 7C22500002 | 22.5792 MHz | 1.8V | ±30ppm | -20°C ~ 70°C |
| 7C40000281 | 40 MHz | 1.8V | ±20ppm | -20°C ~ 75°C |
台湾晶技TXC温补晶振推荐有源晶振7L和7Z系列,能够测量温度,矫正频率,在-30℃~+85℃的工作温度范围内,稳定度最高可达±0.5ppm,极高的温度稳定性,非常适合于GPS、RF中应用。超小型封装可为用户节省设计空间,最小尺寸封装2.0X1.6mm。
